Denon AVR-2312 Service Manual

216
Ref. No. Part No. Part Name Remarks Q'ty New
Q1105 943215500020S TR RT1P141C CVTRT1P141C
Q1106 943216500040S TR RT1N241C CVTRT1N241C
Q1107-1109 943216500050S T.R,RT1N441C(47K-47K) CVTRT1N441C
Q1110 943215500020S TR RT1P141C CVTRT1P141C
Q1111 943216500040S TR RT1N241C CVTRT1N241C
Q1201 943215500020S TR RT1P141C CVTRT1P141C
Q1202 943216500040S TR RT1N241C CVTRT1N241C
Q1203 943215500020S TR RT1P141C CVTRT1P141C
Q1204 943216500040S TR RT1N241C CVTRT1N241C
Q1205 943216500050S T.R,RT1N441C(47K-47K) CVTRT1N441C
Q1502 90M-HY200050R F.E.T (NEC) CVTUPA672T
Q1507 943216500050S T.R,RT1N441C(47K-47K) CVTRT1N441C
Q2008 943215500020S TR RT1P141C CVTRT1P141C
Q2009 943214500020S TR 2SC3052 CVT2SC3052
Q2012,2013 943214500020S TR 2SC3052 CVT2SC3052
Q2301 943215500020S TR RT1P141C CVTRT1P141C
Q2302,2303 943216500020S TR RT1N141C CVTRT1N141C
Q2304,2305 943214500020S TR 2SC3052 CVT2SC3052
Q2306 943214500030S T.R , MUTE INC2001AC1 CVTINC2001AC1
Q2401 943216500020S TR RT1N141C CVTRT1N141C
Q2402 963212500030S T.R , ISA1530AC1 CVTISA1530AC1
Q2403,2404 943214500020S TR 2SC3052 CVT2SC3052
Q2405 963212500030S T.R , ISA1530AC1 CVTISA1530AC1
Q2406-2408 943214500020S TR 2SC3052 CVT2SC3052
Q2411 943214500020S TR 2SC3052 CVT2SC3052
Q2414 943214500020S TR 2SC3052 CVT2SC3052
Q3000 943216500050S T.R,RT1N441C(47K-47K) CVTRT1N441C
Q3003 943229500020S MOSFET,TPC6111(P-CH,U-MOSV) CVTTPC6111
Q3005 943216500050S T.R,RT1N441C(47K-47K) CVTRT1N441C
Q3008 943229500020S MOSFET,TPC6111(P-CH,U-MOSV) CVTTPC6111
Q3009 943216500050S T.R,RT1N441C(47K-47K) CVTRT1N441C
Q3013 943229500020S MOSFET,TPC6111(P-CH,U-MOSV) CVTTPC6111
Q3019 943216500050S T.R,RT1N441C(47K-47K) CVTRT1N441C
Q3021 00D2710326904 T.R,2SA1954 CVT2SA1954
Q3022 943216500050S T.R,RT1N441C(47K-47K) CVTRT1N441C
Q3023 943229500020S MOSFET,TPC6111(P-CH,U-MOSV) CVTTPC6111
Q3025 00D2710326904 T.R,2SA1954 CVT2SA1954
Q3026 943216500020S TR RT1N141C CVTRT1N141C
Q3027 00D2710326904 T.R,2SA1954 CVT2SA1954
Q3028 943216500020S TR RT1N141C CVTRT1N141C
Q3031 00D2710326904 T.R,2SA1954 CVT2SA1954
Q3032 943216500020S TR RT1N141C CVTRT1N141C
Q3034 00D2710326904 T.R,2SA1954 CVT2SA1954
Q3035 943216500020S TR RT1N141C CVTRT1N141C
Q3036 00D2710326904 T.R,2SA1954 CVT2SA1954
Q3037 943216500020S TR RT1N141C CVTRT1N141C
Q3038 943214500020S TR 2SC3052 CVT2SC3052
Q3200 943229500020S MOSFET,TPC6111(P-CH,U-MOSV) CVTTPC6111
Q3201 943216500020S TR RT1N141C CVTRT1N141C
Q3900 943215500020S TR RT1P141C CVTRT1P141C
Q3901 943216500020S TR RT1N141C CVTRT1N141C
Q4001 943216500020S TR RT1N141C CVTRT1N141C
Q4002 943215500020S TR RT1P141C CVTRT1P141C
Q4003 943216500020S TR RT1N141C CVTRT1N141C
D1141 00D2760718902 DIODE, SCHOTTKY, 30V CVDRB521S-30
D2001,2002 00D2760794900 DIODE, ULTRA-HIGH SPEED CVDKDS160RTKP
D2004 nsp RES, CHIP(1608/5%/470Kohm) CRJ10DJ474T
D2007 943209001080S DIODE 1SS355T CVD1SS355T
D2008,2009 00D2760718902 DIODE, SCHOTTKY, 30V CVDRB521S-30
D2301 00D2760794900 DIODE, ULTRA-HIGH SPEED CVDKDS160RTKP
D3001,3002 00D2760794900 DIODE, ULTRA-HIGH SPEED CVDKDS160RTKP
RESISTORS GROUP
R1225,1226 nsp RES, CHIP(1608/1%/1Kohm) CRJ10DF1001T
R1523,1524 nsp RES, CHIP(1608/1%/2.7Kohm) CRJ10DF2701T
R1528 nsp RES, CHIP(1608/1%/220ohm) CRJ10DF2200T

Denon AVR-2312 Specifications

General

Impedance	8 Ω
Speaker selector	A+B
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.08 %
Power output per channel (1KHz@8 Ohm)	135 W
Power output per channel (20-20KHz@8 Ohm)	105 W
HDMI in	7
Composite video in	4
Ethernet LAN (RJ-45) ports	1
Multichannel audio input type	RCA
Component video (YPbPr/YCbCr) in	2
Headphone connectivity	6.3 mm
Connectivity technology	Wired
Speakers connectivity type	Binding post
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Image formats supported	JPG
Wi-Fi	No
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Preset stations quantity	56
Internet radio services supported	Last.fm, Napster
Supported video modes	1080i, 1080p, 480i, 480p, 576i, 576p, 720p
Display	VFD
HDMI version	1.4a
Product color	Black
Audio decoders	Dolby Pro Logic IIz, Dolby TrueHD, DTS-HD Master Audio
Volume control	Rotary
Apple docking compatibility	iPad, iPhone, iPod
Number of products included	1 pc(s)
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	600 W

Weight and Dimensions

Depth	382 mm
Width	434 mm
Height	167 mm
Weight	11000 g
