Denon AVR-2312 Service Manual

217
Ref. No. Part No. Part Name Remarks Q'ty New
R1529 nsp RES, CHIP(1608/1%/3.9Kohm) CRJ10DF3901T
R1530 nsp RES, CHIP(1608/1%/220ohm) CRJ10DF2200T
R1531 nsp RES, CHIP(1608/1%/3.9Kohm) CRJ10DF3901T
R1532,1533 nsp RES, CHIP(1608/1%/180ohm) CRJ10DF1800T
R1575,1576 nsp RES, CHIP(1608/1%/1Kohm) CRJ10DF1001T
R1611 nsp RES, CHIP(1608/1%/2.2Kohm) CRJ10DF2201T
R1612 nsp RES, CHIP(1608/1%/1.3Kohm) CRJ10DF1301T
R1635,1636 nsp RES, CHIP(1608/1%/51ohm) CRJ10DF51R0T
R3003 nsp RES, CHIP(1608/1%/47Kohm) CRJ10DF4702T
R3009 nsp RES, CHIP(1608/1%/47Kohm) CRJ10DF4702T
R3015 nsp RES, CHIP(1608/1%/120Kohm) CRJ10DF1203T
R3020 nsp RES, CHIP(1608/1%/300Kohm) CRJ10DF3003T
R3026 nsp RES, CHIP(1608/1%/470Kohm) CRJ10DF4703T
R3105 nsp RES, CHIP(1608/1%/120Kohm) CRJ10DF1203T
R3223 nsp RES, CHIP(1005/1%/6.8Kohm) CRJ06IF6801T
R3224 nsp RES, CHIP(1005/1%/5.6Kohm) CRJ06IF5601T
CAPACITORS GROUP
C1001 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C1003-1006 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C1007 nsp CHIP CAP 10UF 6.3V CCUC0J106KC
C1008-1012 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C1013 nsp CAP, CHIP(1005, 25V/0.01uF) CCUI1E103KC
C1014 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C1015 nsp CHIP CAP 10UF 6.3V CCUC0J106KC
C1016 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C1017 nsp CHIP CAP 10UF 6.3V CCUC0J106KC
C1018-1020 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C1021-1029 nsp CHIP CAP 10UF 6.3V CCUC0J106KC
C1101-1104 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C1112-1114 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C1115 nsp CHIP CAP 10UF 6.3V CCUC0J106KC
C1116 nsp CHIP CAP 1000PF 50VK CCUS1H102KC
C1117-1120 nsp CHIP CAP 0.1UF 16V
CCUI1C104KC
C1201,1202 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C1204 nsp CHIP CAP 10UF 6.3V CCUC0J106KC
C1205 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C1206 nsp CAP, CHIP(1005, 25V/0.01uF) CCUI1E103KC
C1207,1208 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C1209,1210 nsp CAP, CHIP(1005, 25V/0.01uF) CCUI1E103KC
C1211,1212 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C1213 nsp CAP, CHIP(1005, 25V/0.01uF) CCUI1E103KC
C1214,1215 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C1216 nsp CAP, CHIP(1005, 25V/0.01uF) CCUI1E103KC
C1217 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C1218 nsp CAP, CHIP(1005, 25V/0.01uF) CCUI1E103KC
C1219-1221 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C1222 nsp CHIP CAP 10UF 6.3V CCUC0J106KC
C1223 nsp CAP, CHIP(1005, 25V/0.01uF) CCUI1E103KC
C1224 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C1225 nsp CHIP CAP 10UF 6.3V CCUC0J106KC
C1226-1228 nsp CAP, CHIP(1005, 25V/0.01uF) CCUI1E103KC
C1229-1231 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C1232 nsp CAP, CHIP(1005, 25V/0.01uF) CCUI1E103KC
C1233-1235 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C1236 nsp CHIP CAP 10UF 6.3V CCUC0J106KC
C1237-1239 nsp CAP, CHIP(1005, 25V/0.01uF) CCUI1E103KC
C1240-1247 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C1248 nsp CHIP CAP 10UF 6.3V CCUC0J106KC
C1249 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C1250,1251 nsp CAP, CHIP(1005, 50V/15pF) CCUI1H150JA
C1252 nsp CAP, CHIP(1005, 50V/1000pF) CCUI1H102KC
C1253-1256 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C1257 nsp CAP, CHIP(1005, 50V/1000pF) CCUI1H102KC
C1259-1262 nsp CAP, CHIP(1005, 25V/0.01uF) CCUI1E103KC
C1263 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C1264,1265 nsp CAP, CHIP(1005, 25V/0.01uF) CCUI1E103KC

Denon AVR-2312 Specifications

General

Impedance	8 Ω
Speaker selector	A+B
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.08 %
Power output per channel (1KHz@8 Ohm)	135 W
Power output per channel (20-20KHz@8 Ohm)	105 W
HDMI in	7
Composite video in	4
Ethernet LAN (RJ-45) ports	1
Multichannel audio input type	RCA
Component video (YPbPr/YCbCr) in	2
Headphone connectivity	6.3 mm
Connectivity technology	Wired
Speakers connectivity type	Binding post
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Image formats supported	JPG
Wi-Fi	No
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Preset stations quantity	56
Internet radio services supported	Last.fm, Napster
Supported video modes	1080i, 1080p, 480i, 480p, 576i, 576p, 720p
Display	VFD
HDMI version	1.4a
Product color	Black
Audio decoders	Dolby Pro Logic IIz, Dolby TrueHD, DTS-HD Master Audio
Volume control	Rotary
Apple docking compatibility	iPad, iPhone, iPod
Number of products included	1 pc(s)
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	600 W

Weight and Dimensions

Depth	382 mm
Width	434 mm
Height	167 mm
Weight	11000 g
