Denon AVR-2312 Service Manual

219
Ref. No. Part No. Part Name Remarks Q'ty New
C1579 nsp CAP, CHIP(1005, 25V/0.012uF) CCUI1E123KC
C1580 nsp CAP, CHIP(1608, 16V/0.15uF) CCUS1C154KC
C1581 nsp CAP, CHIP(1005, 25V/0.012uF) CCUI1E123KC
C1582,1583 nsp CAP, CHIP(1005, 50V/2200pF) CCUI1H222KC
C1588 nsp CHIP CAP 1UF 10V CCUS1A105KC
C1590,1591 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C1594-1625 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C1626 nsp CHIP CAP 1UF 10V CCUS1A105KC
C1627 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C1628 nsp CAP, CHIP(1005, 50V/1000pF) CCUI1H102KC
C1629 nsp CHIP CAP 1UF 10V CCUS1A105KC
C1630,1631 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C1632,1633 nsp CHIP CAP 10UF 6.3V CCUC0J106KC
C1634 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C1635 nsp CHIP CAP 10UF 6.3V CCUC0J106KC
C1637 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C1640 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C1641 nsp CHIP CAP 10UF 6.3V CCUC0J106KC
C1643-1648 nsp CAP, CHIP(1005, 25V/0.01uF) CCUI1E103KC
C1649 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C1650,1651 nsp CAP, CHIP(1005, 25V/0.01uF) CCUI1E103KC
C1652 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C1653 nsp CAP, CHIP(1005, 25V/0.01uF) CCUI1E103KC
C1654 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C1655,1656 nsp CAP, CHIP(1005, 25V/0.01uF) CCUI1E103KC
C1657 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C1658 nsp CAP, CHIP(1005, 25V/0.01uF) CCUI1E103KC
C1659 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C1660 nsp CAP, CHIP(1005, 25V/0.01uF) CCUI1E103KC
C1662 nsp CHIP CAP 1UF 10V CCUS1A105KC
C1665 nsp CHIP CAP 10UF 6.3V CCUC0J106KC
C1670 nsp CHIP CAP 10UF 6.3V CCUC0J106KC
C1671 nsp CAP, CHIP(1005, 25V/0.01uF) CCUI1E103KC
C1672 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C1673 nsp CHIP CAP 10UF 6.3V CCUC0J106KC
C1674 nsp CAP, CHIP(1005, 25V/0.01uF) CCUI1E103KC
C1675 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C2001 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C2002 nsp CHIP CAP 0.1UF 50V K CCUS1H104KC
C2003 nsp CHIP CAP 1000PF 50VK CCUS1H102KC
C2004 nsp CHIP CAP 0.1UF 50V K CCUS1H104KC
C2005 nsp CHIP CAP 1000PF 50VK CCUS1H102KC
C2012-2015 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C2018 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C2024,2025 nsp CAP, CHIP(1608, 50V/12pF) CCUS1H120JA
C2026 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C2029-2032 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C2037 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C2039 nsp CAP, CHIP(1005, 25V/0.01uF) CCUI1E103KC
C2042,2043 nsp CHIP CAP 0.01UF 50V K CCUS1H103KC
C2044-2053 nsp CHIP CAP 1000PF 50VK CCUS1H102KC
C2301,2302 nsp CAP, CHIP(1608, 50V/10pF) CCUS1H100JA
C2303 nsp CHIP CAP 0.1UF 50V K CCUS1H104KC
C2304 nsp CAP, CHIP(1608, 10V/0.47uF) CCUS1A474KC
C2310 nsp CHIP CAP 0.1UF 50V K CCUS1H104KC
C2311 nsp CHIP CAP 220PF 50V CCUS1H221JA
C2312 nsp CHIP CAP 0.1UF 50V K CCUS1H104KC
C2314-2316 nsp CHIP CAP 0.1UF 50V K CCUS1H104KC
C2325,2326 nsp CAP, CHIP(1005, 50V/1000pF) CCUI1H102KC
C2401,2402 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C2403 nsp CHIP CAP 0.1UF 50V K CCUS1H104KC
C2404-2407 nsp CAP, CHIP(1005, 25V/0.01uF) CCUI1E103KC
C2408-2410 nsp CHIP CAP 0.01UF 50V K CCUS1H103KC
C2908 nsp CAP, CHIP(1005, 50V/1000pF) CCUI1H102KC
C2910-2917 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C2922-2925 nsp
CHIP CAP 0.1UF 16V CCUI1C104KC
C2932-2943 nsp CAP, CHIP(1005, 50V/1000pF) CCUI1H102KC

Denon AVR-2312 Specifications

General

Impedance	8 Ω
Speaker selector	A+B
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.08 %
Power output per channel (1KHz@8 Ohm)	135 W
Power output per channel (20-20KHz@8 Ohm)	105 W
HDMI in	7
Composite video in	4
Ethernet LAN (RJ-45) ports	1
Multichannel audio input type	RCA
Component video (YPbPr/YCbCr) in	2
Headphone connectivity	6.3 mm
Connectivity technology	Wired
Speakers connectivity type	Binding post
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Image formats supported	JPG
Wi-Fi	No
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Preset stations quantity	56
Internet radio services supported	Last.fm, Napster
Supported video modes	1080i, 1080p, 480i, 480p, 576i, 576p, 720p
Display	VFD
HDMI version	1.4a
Product color	Black
Audio decoders	Dolby Pro Logic IIz, Dolby TrueHD, DTS-HD Master Audio
Volume control	Rotary
Apple docking compatibility	iPad, iPhone, iPod
Number of products included	1 pc(s)
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	600 W

Weight and Dimensions

Depth	382 mm
Width	434 mm
Height	167 mm
Weight	11000 g
