Denon AVR-2312 Service Manual

220
Ref. No. Part No. Part Name Remarks Q'ty New
C3000 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C3002 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C3003 nsp CHIP CAP 10UF 6.3V CCUC0J106KC
C3004 nsp CAP,CHIP(2012,10V/22uF) CCUC1A226KC
C3007 nsp CAP, CHIP(1005, 25V/0.01uF) CCUI1E103KC
C3008 nsp CAP, CHIP(1608, 50V/10pF) CCUS1H100JA
C3011 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C3013 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C3014 nsp CHIP CAP 10UF 6.3V CCUC0J106KC
C3015 nsp CAP,CHIP(2012,10V/22uF) CCUC1A226KC
C3018 nsp CAP, CHIP(1005, 25V/0.01uF) CCUI1E103KC
C3019 nsp CAP, CHIP(1608, 50V/10pF) CCUS1H100JA
C3022 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C3024 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C3025 nsp CHIP CAP 10UF 6.3V CCUC0J106KC
C3028 nsp CAP,CHIP(2012,10V/22uF) CCUC1A226KC
C3029 nsp CHIP CAP 15PF 50V CCUS1H150JA
C3031 nsp CHIP CAP 10UF 6.3V CCUC0J106KC
C3032 nsp CAP, CHIP(1005, 25V/0.01uF) CCUI1E103KC
C3033 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C3035 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C3036 nsp CHIP CAP 10UF 6.3V CCUC0J106KC
C3039 nsp CAP, CHIP(1005, 25V/0.01uF) CCUI1E103KC
C3040 nsp CHIP CAP 15PF 50V CCUS1H150JA
C3041 nsp CAP,CHIP(2012,10V/22uF) CCUC1A226KC
C3044 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C3046 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C3049 nsp CAP, CHIP(1005, 25V/0.01uF) CCUI1E103KC
C3050 nsp CHIP CAP 15PF 50V CCUS1H150JA
C3051 nsp CAP,CHIP(2012,10V/22uF) CCUC1A226KC
C3054 nsp CHIP CAP 10UF 6.3V CCUC0J106KC
C3055 nsp CAP, CHIP(1005, 25V/0.022uF) CCUI1E223KC
C3056 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C3059-3062 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C3067,3068 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C3071 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C3074 943134500030S CAP, SMD ELECT(16V/470uF) CCEC1CRV471T
C3075 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C3077 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C3079 943134500030S CAP, SMD ELECT(16V/470uF/MANLEX
RV, 10X10)
E2,EA CCEC1CRV471T
C3080 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C3081 nsp CHIP CAP 0.015UF 25V CCUI1E153KC
C3082 nsp CHIP CAP 1UF 10V CCUS1A105KC
C3083,3084 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C3087 nsp CAP, CHIP(1005, 50V/1000pF) CCUI1H102KC
C3102 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C3103 nsp CHIP CAP 10UF 6.3V CCUC0J106KC
C3106 nsp CAP,CHIP(2012,10V/22uF) CCUC1A226KC
C3107 nsp CHIP CAP 15PF 50V CCUS1H150JA
C3108 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C3109 nsp CHIP CAP 10UF 6.3V CCUC0J106KC
C3110 nsp CAP, CHIP(1005, 25V/0.01uF) CCUI1E103KC
C3144 nsp CHIP CAP 10UF 6.3V CCUC0J106KC
C3145,3146 nsp CHIP CAP 1UF 10V CCUS1A105KC
C3147 nsp CHIP CAP 10UF 6.3V CCUC0J106KC
C3156 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C3200 nsp CAP, CHIP(1005, 50V/1000pF) CCUI1H102KC
C3201 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C3202 nsp CAP, CHIP(1005, 25V/0.022uF) CCUI1E223KC
C3203 nsp CAP, CHIP(1005, 50V/1000pF) CCUI1H102KC
C3204 nsp CAP, CHIP(1608,6.3V/4.7uF) CCUS0J475KC
C3205 nsp CAP, CHIP(1005, 50V/1000pF) CCUI1H102KC
C3206 nsp CAP, CHIP(1608,6.3V/4.7uF) CCUS0J475KC
C3207,3208 nsp CAP, CHIP(1005, 50V/15pF) CCUI1H150JA
C3209 nsp CAP, CHIP(1005, 50V/1000pF) CCUI1H102KC

Denon AVR-2312 Specifications

General

Impedance	8 Ω
Speaker selector	A+B
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.08 %
Power output per channel (1KHz@8 Ohm)	135 W
Power output per channel (20-20KHz@8 Ohm)	105 W
HDMI in	7
Composite video in	4
Ethernet LAN (RJ-45) ports	1
Multichannel audio input type	RCA
Component video (YPbPr/YCbCr) in	2
Headphone connectivity	6.3 mm
Connectivity technology	Wired
Speakers connectivity type	Binding post
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Image formats supported	JPG
Wi-Fi	No
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Preset stations quantity	56
Internet radio services supported	Last.fm, Napster
Supported video modes	1080i, 1080p, 480i, 480p, 576i, 576p, 720p
Display	VFD
HDMI version	1.4a
Product color	Black
Audio decoders	Dolby Pro Logic IIz, Dolby TrueHD, DTS-HD Master Audio
Volume control	Rotary
Apple docking compatibility	iPad, iPhone, iPod
Number of products included	1 pc(s)
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	600 W

Weight and Dimensions

Depth	382 mm
Width	434 mm
Height	167 mm
Weight	11000 g
