Denon AVR-2312 Service Manual

221
Ref. No. Part No. Part Name Remarks Q'ty New
C3210,3211 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C3213 nsp CAP, CHIP(1608,6.3V/4.7uF) CCUS0J475KC
C3215,3216 nsp CAP, CHIP(1608,6.3V/4.7uF) CCUS0J475KC
C3218 nsp CAP, CHIP(1608,6.3V/4.7uF) CCUS0J475KC
C3219-3222 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C3223 nsp CAP, CHIP(1005, 50V/1000pF) CCUI1H102KC
C3224,3225 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C3226 nsp CAP, CHIP(1608,6.3V/4.7uF) CCUS0J475KC
C3228,3229 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C3234 nsp CAP, CHIP(1608,6.3V/4.7uF) CCUS0J475KC
C3243-3247 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C3248,3249 nsp CAP, CHIP(1005, 50V/1pF) CCUI1H1R0CA
C3253 nsp CHIP CAP 1000PF 50VK CCUS1H102KC
C3255 nsp CHIP CAP 1000PF 50VK CCUS1H102KC
C3900 nsp CAP, CHIP(1005, 50V/1000pF) CCUI1H102KC
C3901,3902 nsp CAP, CHIP(1005, 50V/12pF) CCUI1H120JA
C3904-3907 nsp CAP, CHIP(1608,6.3V/4.7uF) CCUS0J475KC
C3908-3918 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C3923 nsp CAP, CHIP(1608,6.3V/4.7uF) CCUS0J475KC
C3926-3929 nsp CAP, CHIP(1608,6.3V/4.7uF) CCUS0J475KC
C3930-3939 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C3944 nsp CAP, CHIP(1608,6.3V/4.7uF) CCUS0J475KC
C3947 nsp CAP, CHIP(1608,6.3V/4.7uF) CCUS0J475KC
C3950-3958 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C3960-3966 nsp CAP, CHIP(1005, 50V/1000pF) CCUI1H102KC
C4003,4004 nsp CAP, CHIP(1005, 25V/0.01uF) CCUI1E103KC
C4005-4008 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C4009,4010 nsp CAP, CHIP(1005, 25V/0.01uF) CCUI1E103KC
C4012-4014 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C4015 nsp CHIP CAP 0.022UF 50VK CCUS1H223KC
C4016,4017 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C4018 nsp CAP, CHIP(1005, 50V/1000pF) CCUI1H102KC
C4020 nsp CHIP CAP 10UF 6.3V CCUC0J106KC
C4021 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C4022,4023 nsp CAP, CHIP(1005, 50V/12pF) CCUI1H120JA
C4024-4029 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C4030 nsp CHIP CAP 0.022UF 50VK CCUS1H223KC
C4031,4032 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C4033 nsp CAP, CHIP(1005, 50V/1000pF) CCUI1H102KC
C4034-4037 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C4049-4051 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C4052 nsp CAP, CHIP(1005, 50V/1000pF) CCUI1H102KC
C4053,4054 nsp CAP, CHIP(1005, 50V/100pF) CCUI1H101JA
C4055-4060 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C4063 nsp CAP, CHIP(1005, 50V/100pF) CCUI1H101JA
C4064-4066 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C4067,4068 nsp CAP, CHIP(1608, 50V/9pF) CCUS1H090DA
C4069-4114 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C4121-4168 nsp CAP, CHIP(1005, 50V/1000pF) CCUI1H102KC
C4174,4175 nsp CAP, CHIP(1005, 50V/1000pF) CCUI1H102KC
C4402 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C4404-4407 nsp CAP, CHIP(2012, 10V/4.7uF) CCUC1A475ZF
C4408 943134500040S CAP, CHIP ELECT(16V/100uF) HCEC1CRV2101T
C4411,4412 nsp CHIP CAP 3900PF 50V K CCUS1H392KC
C4423-4426 nsp CAP, CHIP(1608, 50V/680pF) CCUS1H681JA
C4429,4430 943134500040S CAP, CHIP ELECT(16V/100uF) HCEC1CRV2101T
C4431,4432 nsp CHIP CAP 3900PF 50V K CCUS1H392KC
C4443-4446 nsp CAP, CHIP(1608, 50V/680pF) CCUS1H681JA
C4451,4452 nsp CHIP CAP 3900PF 50V K CCUS1H392KC
C4463-4466 nsp CAP, CHIP(1608, 50V/470pF) CCUS1H471JA
C4471,4472 nsp CHIP CAP 3900PF 50V K CCUS1H392KC
C4483-4486 nsp CAP, CHIP(1608, 50V/680pF) CCUS1H681JA
C4491,4492 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C4493,4494 nsp CAP, CHIP(1005, 50V/1000pF) CCUI1H102KC
C4497-4499 nsp CAP, CHIP(1005, 50V/1000pF) CCUI1H102KC
C4505,4506 nsp
CHIP CAP 4700PF 50V CCUS1H472KC
C4507,4508 943134500050S CAP, CHIP ELECT(16V/10uF) HCEC1CRV2100T

Denon AVR-2312 Specifications

General

Impedance	8 Ω
Speaker selector	A+B
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.08 %
Power output per channel (1KHz@8 Ohm)	135 W
Power output per channel (20-20KHz@8 Ohm)	105 W
HDMI in	7
Composite video in	4
Ethernet LAN (RJ-45) ports	1
Multichannel audio input type	RCA
Component video (YPbPr/YCbCr) in	2
Headphone connectivity	6.3 mm
Connectivity technology	Wired
Speakers connectivity type	Binding post
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Image formats supported	JPG
Wi-Fi	No
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Preset stations quantity	56
Internet radio services supported	Last.fm, Napster
Supported video modes	1080i, 1080p, 480i, 480p, 576i, 576p, 720p
Display	VFD
HDMI version	1.4a
Product color	Black
Audio decoders	Dolby Pro Logic IIz, Dolby TrueHD, DTS-HD Master Audio
Volume control	Rotary
Apple docking compatibility	iPad, iPhone, iPod
Number of products included	1 pc(s)
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	600 W

Weight and Dimensions

Depth	382 mm
Width	434 mm
Height	167 mm
Weight	11000 g
