Denon AVR-2312 Service Manual

222
Ref. No. Part No. Part Name Remarks Q'ty New
C4511,4512 nsp CHIP CAP 1UF 10V CCUS1A105KC
C4513,4514 nsp CAP, CHIP(2012, 10V/4.7uF) CCUC1A475ZF
C4516 nsp CHIP CAP 1000PF 50VK CCUS1H102KC
C4537,4538 nsp CAP, CHIP(1005, 50V/1000pF) CCUI1H102KC
C4540-4542 nsp CAP, CHIP(1005, 50V/1000pF) CCUI1H102KC
C4544 nsp CAP, CHIP(1005, 50V/1000pF) CCUI1H102KC
C4551 nsp CHIP CAP 1UF 10V CCUS1A105KC
C4552,4553 nsp CAP, CHIP(2012, 10V/4.7uF) CCUC1A475ZF
C4554 nsp CHIP CAP 1UF 10V CCUS1A105KC
C4557,4558 nsp CAP, CHIP(1608, 50V/2200pF) CCUS1H222KC
C4560 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C4581 nsp CAP, CHIP(1005, 50V/1000pF) CCUI1H102KC
C4583-4591 nsp CAP, CHIP(1005, 50V/1000pF) CCUI1H102KC
C4593 nsp CAP, CHIP(1005, 50V/1000pF) CCUI1H102KC
OTHERS PARTS GROUP
BK101,102 nsp PCB BRACKET CMD1A569
BK103 nsp EARTH , HDMI CMC1A422
CN101 nsp WAFER CARD CABLE 23P, 1.0MM CJP23GA193ZY
CN121 nsp WAFER CARD CABLE 23P, 1.0MM CJP23GA193ZY
CN203 nsp WAFER , SMD (2MM PITCH)-3P CJP03GA208ZY
CN21B nsp PIN SOCKET (15P,1.25mm,ANGLE, B-TO-
B)
CJP15HJ282Z
CN22B nsp PIN SOCKET (17P,1.25mm,ANGLE, B-TO-
B) P
CJP17HJ282Z
CN23B nsp PIN SOCKET (13P,1.25mm,ANGLE, B-TO-
B)
CJP13HJ282Z
CN24B nsp PIN SOCKET (27P,1.25mm,ANGLE, B-TO-
B)
CJP27HJ282Z
CN25B nsp PIN SOCKET (17P,1.25mm,ANGLE, B-TO-
B) P
CJP17HJ282Z
CN26B nsp PIN SOCKET (15P,1.25mm,ANGLE, B-TO-
B)
CJP15HJ282Z
CN27B nsp PIN SOCKET (21P,1.25mm,ANGLE, B-TO-
B)
CJP21HJ282Z
CN28B nsp PIN SOCKET (11P,1.25mm,ANGLE, B-TO-
B)
CJP11HJ282Z
CN321 nsp WAFER SMD(2MMPITCH) CJP05GA208ZY
CN69B nsp WAFER, FFC, 40P, 1mm(SMD) CJP40GA193ZY
CN704 nsp WAFER SMD(2MMPITCH)
CJP05GA208ZY
CN903 nsp LOCK-WAFER/STRAIGHT/2.5MM
PITCH/5PIN
CJP05GI289ZY
J3200 943646100430S JACK, RJ-45 CJJ9L022Z *
JK101 943643100040S JACK,HDMI(KSI-TWI,W/FLANGE) CJJ9H014Z
JK111-114 943643100040S JACK,HDMI(KSI-TWI,W/FLANGE) CJJ9H014Z
JK121,122 943643100040S JACK,HDMI(KSI-TWI,W/FLANGE) CJJ9H014Z
JK152 943643100040S JACK,HDMI(KSI-TWI,W/FLANGE) CJJ9H014Z
JK201 943643010220S JACK 3.5PIHORIZONTALWITHOUTRING CJJ2E033Z
JK202,203 643010086002S JACK, STEREO (BLK MOLD) CJJ2D008Z
JK401 943643101110S JACK, 2P O (RCA-215A-00-01) CJJ4N068Y
JK402,403 262010004005S MODULE , OPTICAL (RX,3.3V) HJSTORX147L
L1001,1002 nsp RES,CHIP(0OHM,5%,1608) CRJ10DJ0R0T
L1102 nsp RES,CHIP(0OHM,5%,1608) CRJ10DJ0R0T
L1201-1207 nsp CHIP FERRITE BEAD(60ohm 1608) CLZ9R005Z
L1501-1512 nsp CHIP FERRITE BEAD(60ohm 1608) CLZ9R005Z
L1513 nsp COIL , CHIP(22uH, 3225) CLQ10E220KRX
L1514,1515 nsp CHIP FERRITE BEAD(60ohm 1608) CLZ9R005Z
L1517 nsp CHIP FERRITE BEAD(60ohm 1608) CLZ9R005Z
L1518 nsp COIL , CHIP(22uH, 3225) CLQ10E220KRX

Denon AVR-2312 Specifications

General

Impedance	8 Ω
Speaker selector	A+B
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.08 %
Power output per channel (1KHz@8 Ohm)	135 W
Power output per channel (20-20KHz@8 Ohm)	105 W
HDMI in	7
Composite video in	4
Ethernet LAN (RJ-45) ports	1
Multichannel audio input type	RCA
Component video (YPbPr/YCbCr) in	2
Headphone connectivity	6.3 mm
Connectivity technology	Wired
Speakers connectivity type	Binding post
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Image formats supported	JPG
Wi-Fi	No
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Preset stations quantity	56
Internet radio services supported	Last.fm, Napster
Supported video modes	1080i, 1080p, 480i, 480p, 576i, 576p, 720p
Display	VFD
HDMI version	1.4a
Product color	Black
Audio decoders	Dolby Pro Logic IIz, Dolby TrueHD, DTS-HD Master Audio
Volume control	Rotary
Apple docking compatibility	iPad, iPhone, iPod
Number of products included	1 pc(s)
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	600 W

Weight and Dimensions

Depth	382 mm
Width	434 mm
Height	167 mm
Weight	11000 g
