Denon AVR-2312 Service Manual

223
Ref. No. Part No. Part Name Remarks Q'ty New
L1521,1522 nsp CHIP FERRITE BEAD(60ohm 1608) CLZ9R005Z
L2903-2934 nsp RES,CHIP(0OHM,5%,1608) CRJ10DJ0R0T
L3000-3009 nsp RES, CHIP(3216/5%/0ohm) CRJ14CJ0R0T
L3011-3013 nsp FERRITE CHIP BEAD(2012/220ohm) CLZBLM21PG221SN1
L3014 nsp FERRITE CHIP BEAD(2012/120ohm) CLZBLM21AG121SN1
L3015,3016 nsp RES, CHIP(3216/5%/0ohm) CRJ14CJ0R0T
L3081-3086 nsp RES, CHIP(3216/5%/0ohm) CRJ14CJ0R0T
L3200,3201 nsp COIL, CHOKE CHIP(2012/90R) CLZ9Z128Z
L3202-3206 nsp FERRITE CHIP BEAD(2012/220ohm) CLZ9R006Z
L3208 nsp FERRITE CHIP BEAD(2012/220ohm) CLZ9R006Z
L3211 nsp RES, CHIP(2012/5%/0ohm) CRJ18AJ0R0T
L3212 nsp COIL, CHOKE CHIP(2012/180R) CLZ9Z127Z
L3213,3214 nsp RES, CHIP(2012/5%/0ohm) CRJ18AJ0R0T
L3900-3902 nsp FERRITE CHIP BEAD(2012/220ohm) CLZ9R006Z
X1201 141810044504S CRYSTAL, SMD, 28.6363MHz COX286363I120SR
X1501 141810045507S CRYSTAL, SMD, 27MHz COX27000I330SR
X2001 00D3991038900 CRYSTAL, SMD, 12MHz COX12000I100SR
X2301 141810048506S CRYSTAL, SMD, 16MHz COX16000I100SR
X3900 141810049509S CRYSTAL, SMD, 24MHz COX24000I120SR
X4001 141810046500S CRYSTAL, SMD, 24.576MHz COX24576I100SR
X4002 943141100020S CRYSTAL, SMD, 21.875MHz COX21875I070SR

Denon AVR-2312 Specifications

General

Impedance	8 Ω
Speaker selector	A+B
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.08 %
Power output per channel (1KHz@8 Ohm)	135 W
Power output per channel (20-20KHz@8 Ohm)	105 W
HDMI in	7
Composite video in	4
Ethernet LAN (RJ-45) ports	1
Multichannel audio input type	RCA
Component video (YPbPr/YCbCr) in	2
Headphone connectivity	6.3 mm
Connectivity technology	Wired
Speakers connectivity type	Binding post
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Image formats supported	JPG
Wi-Fi	No
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Preset stations quantity	56
Internet radio services supported	Last.fm, Napster
Supported video modes	1080i, 1080p, 480i, 480p, 576i, 576p, 720p
Display	VFD
HDMI version	1.4a
Product color	Black
Audio decoders	Dolby Pro Logic IIz, Dolby TrueHD, DTS-HD Master Audio
Volume control	Rotary
Apple docking compatibility	iPad, iPhone, iPod
Number of products included	1 pc(s)
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	600 W

Weight and Dimensions

Depth	382 mm
Width	434 mm
Height	167 mm
Weight	11000 g
