89
Timing waveform illustration from the start of CEC3.3V to when reset is released : Check items (31)
DV3.3V
8002_RESET
314ms
DV3.3V
8002_RESET
10ms 10ms
Timing waveform illustration from the start of CEC3.3V to when reset is released : Check items (27)
CEC3.3V
7844_RESET
338ms
