Denon AVR-2808 Service Manual

120
AVR-2808
14
00D 144 3031 020 DOOR 2808SPE2A 1 *
15
00D 401 0195 202 HINGE (L) 2808BKE2 1
15
00D 401 0195 215 HINGE (L) 2808SRE2 1
15
00D 401 0195 231 HINGE (L) 2808SPE2A 1
16
00D 401 0196 201 HINGE (R) 2808BKE2 1
16
00D 401 0196 214 HINGE (R) 2808SRE2 1
16
00D 401 0196 230 HINGE (R) 2808SPE2A 1
17
00D 114 0204 008 KNOB RING(M) 2808BKE2 1
17
00D 114 0204 011 KNOB RING(M) 2808SRE2 1
17
00D 114 0204 024 KNOB RING(M) 2808SPE2A 1
18
00D 114 0203 009 KNOB RING(F) 2808BKE2 1
18
00D 114 0203 012 KNOB RING(F) 2808SRE2 1
18
00D 114 0203 025 KNOB RING(F) 2808SPE2A 1
19
00D 112 1005 006 KNOB(M) ASSY 2808BKE2 1
19
00D 112 1005 019 KNOB(M) ASSY 2808SRE2 1
19
00D 112 1005 022 KNOB(M) ASSY 2808SPE2A 1
20
00D 112 1007 004 KNOB(F) ASSY 2808BKE2 1
20
00D 112 1007 017 KNOB(F) ASSY 2808SRE2 1
20
00D 112 1007 020 KNOB(F) ASSY 2808SPE2A 1
21
00D 146 2509 274 INNER PANEL 2808BKE2 1 *
21
00D 146 2509 258 INNER PANEL 2808SRE2 1 *
21
00D 146 2509 261 INNER PANEL 2808SPE2A 1 *
22
00D 143 1295 001 DOOR SHEET 2808BKE2 1 *
22
00D 143 1295 014 DOOR SHEET 2808SRE2 1 *
22
00D 143 1295 027 DOOR SHEET 2808SPE2A 1 *
23
nsp RUBBER SHEET DOOR CLOSE 2
24
nsp RUBBER SHEET DOOR OPEN 2
25
00D 143 1294 002 WINDOW 1
26
00D 113 1996 202 CURSOR KNOB 2808BKE2 1
26
00D 113 1996 215 CURSOR KNOB 2808SRE2 1
26
00D 113 1996 231 CURSOR KNOB 2808SPE2A 1
27
00D 113 1995 041 ENTER KNOB 2808BKE2 1
27
00D 113 1995 012 ENTER KNOB 2808SRE2 1
27
00D 113 1995 038 ENTER KNOB 2808SPE2A 1
28
nsp LENS (POWER) 1
29
00D 113 1992 109 P.KNOB ASSY(SUB) 2808BKE2 1
29
00D 113 1992 112 P.KNOB ASSY(SUB) 2808SRE2 1
29
00D 113 1992 138 P.KNOB ASSY(SUB) 2808SPE2A 1
30
00D 113 1994 107 P.KNOB ASSY(MAIN) 2808BKE2 1
30
00D 113 1994 110 P.KNOB ASSY(MAIN) 2808SRE2 1
30
00D 113 1994 149 P.KNOB ASSY(MAIN) 2808SPE2A 1
31
00D 421 0763 010 GEAR DAMPER 058E-L 1
32
nsp DOOR STOPPER 1
33
nsp FRONT BRACKET 1
34
00D GEN 8688 TOP COVER SUB ASSY 00D1020704000 BK model 1
34
00D GEN 8688-1 TOP COVER SUB ASSY 00D1020704013 SR/SP model 1
35
nsp MAIN CHASSIS 1 *
36
nsp BRACKET 2
37
nsp FOOT 4
38
nsp RUBBER PAD 4
39
nsp SUPPORT BRACKET 1
40
nsp SCREW COVER (BOTTOM) 1
z
42
00D 233 6585 006 MAIN TRANS(28CIE2) 1 *
43
00D 105 1693 122 BACK PANEL 1 *
44
00D 216 0125 001 AM FM TUNER(E2) 1
Ref. No. Part No. Part Name Remarks Q'ty
