Denon AVR-2808 - Page 121

121
AVR-2808
45
00D 205 1116 006 TERMINAL ASS 1
46
nsp SCREW COVER 1
47
nsp PUSH RIVET NRP-345 1
48
nsp RADIATOR 1
49
00D 278 0020 007 2SB1647/2SD2560(P/Y)-LF 7
49-1
- 2SB1647
49-2
- 2SD2560
50
nsp RADIATOR BRACKET (L) 1
51
nsp RADIATOR BRACKET (R) 1
52
nsp H/P PLATE Cut INN.PANEL 1
53
nsp D/S PLATE Cut INN.PANEL 1
54
nsp BKT2 UNIT Cut FRONT UNIT PWB Board 1
55
nsp BKT1 UNIT Cut FRONT UNIT PWB Board 1
56
nsp BKT3 UNIT Cut FRONT UNIT PWB Board 1
★58
nsp LICENSE SUB ASSY MAIN CHASSIS bottom 1
★59
nsp SERIAL NO. SHEET BACK PANEL 1
60
00D 414 1058 001 SAFETY COVER TOP COVER 1
61
00D 449 0139 105 COVER HOLDER 6
★62
00D 415 0845 001 SP RIVET SP TERMINAL 18
63
00D 461 1017 064 RUBBER SHEET 1
64
00D 461 1017 077 RUBBER SHEET 3
81
nsp CARD SPACER (L=8) MPS-08-0 2
82
nsp CARD SPACER(L=10) MPS-10-0 4
83
nsp LOCKING CARD SPACER KGLS-14RT:Fix CPU POWER UNIT 1
84
nsp P.W.B.HOLDER (H=10) KGLS-10RT:Fix MAIN CPU UNIT 1
85
nsp CARD SPACER (H=10) KGPS-10RF:Fix MAIN CPU UNIT 1
★86
nsp WIRE CLAMPER 8
87
nsp RUBBER SHEET 60X25XT2 2
★ 88
nsp RUBBER SHEET 35X25XT2 1
★ 89
nsp CORD HOLDER (L76) 2
★91
nsp CHUKOH TAPE 13X30X0.13 : TOP COVER
Screws
201
00D 477 0064 107 FIXING SCREW 38
202
nsp 3X8 CBTS (S)-Z 21
203
nsp 4X8 TP SCREW 4
204
nsp 3X5 CBTS(S)Z 1
205
nsp 3X6 CBTS(S)-B 34
207
nsp 3X8 CBTS (P)-Z 36
208
nsp 3X8 CFTS (P)-Z 2
210
nsp 3X8 CUP SCREW 1
211
nsp 3X10 CBTS(B)-Z 19
212
0RD 473 8064 000 4X8 CBTS(B)-B-3P BK model 10
212
0RD 473 8064 000 4X8 CBTS(B)-B-3P SR/SP model 2
212
0RD 473 8064 013 4X8 CBTS(B)-N-3P SR/SP model 8
213
nsp 3X16 CPTS(B) SW W 14
Wires
★501
00D 009 0295 058 25P FFC(1.0) CX251(DISP-MAINuCON) 1
★502
00D 009 0295 045 27P FFC(1.0) CX271(FRONTIN-MAINuCON) 1
★503
00D 009 0296 002 15P FFC(1.25) TUNER-MAINuCON 1
★504
nsp 1P SIN CON CORD W-508 1
★505
nsp 2P VA-3P SDN CON.CORD CW021 1
★506
nsp 3P SDN-VH CON.CORD CX035 1
Ref. No. Part No. Part Name Remarks Q'ty
Ne
w
