67
After starting playback
[1] Adjusting the sound quality (TONE)
The tone control function will not work in the PURE DIRECT and the
DIRECT mode.
1
The tone switches as follows each time the TONE CONTROL
button is pressed.
(Main unit)
2
With the name of the volume to be
adjusted selected, press cursor button
to adjust the level.
NOTE:
To prevent hearing loss, do not raise the volume level excessively
when using headphone.
[3] Turning the sound off temporarily (MUTING)
1
Use this to mute the audio output
temporarily.
Press the MUTING button.
Cancelling MUTING mode.
Press the MUTING button again.
• To increase the bass or treble: Press the button.
(The bass or treble sound can be
increased to up to +6 dB in steps of 1 dB.)
• To decrease the bass or treble: Press the button.
(The bass or treble sound can be
decreased to up to –6 dB in steps of 1 dB.)
[2] Listening over headphone
1
Plug the headphone’ plug into the
jack.
Connect the headphone to the
PHONES jack.
The pre-out output (including
the speaker output) is
automatically turned off when
headphone are connected.
(Main unit)
(Remote control unit)
3
If you do not want the bass and treble to be adjusted, turn on
the tone defeat mode.
The signals do not pass through the
bass and treble adjustment circuits,
providing higher quality sound.
[4]
Combining the currently playing sound with the desired image
1
Simulcast playback
Use this switch to monitor a
video source other than the
audio source.
Press the VIDEO SELECT
button, turn the FUNCTION
knob until the desired
source appears on the
display.
Cancelling simulcast playback.
• Select “SOURCE” using the VIDEO SELECT button and
the FUNCTION button.
• Switch the program source to the component connected
to the video input.
• Press the SOURCE button.
(Main unit)
To Next Page
