Denon AVR-391 Owner's Manual

8
ENGLISH
Set up speakers
Remote control operation
buttons
Move the cursor
(Up/Down/Left/Right)
Confi rm the setting Return to previous menu
3
Use ui to select “Mode”, and use
o p to select a detailed setting.
Mode :• LFE –
Mode
Select low range signals to be
reproduced by subwoofer.
• LFE : The low range signal of the channel set to
“Small” speaker size is added to the LFE signal
output from the subwoofer.
• LFE+Main : The low range signal of all channels
is added to the LFE signal output from the
subwoofer.
• “Mode” can be set when “Speaker Confi g.” –
“SW” (vpage7) is set to “Yes”.
• Play music or a movie source and select the
mode offering the strongest bass.
• Select “LFE+Main” if you want the bass signals
to always be produced from the subwoofer.
NOTE
If “Front” and “Center” for “Speaker Confi g.”
are set to “Large”, and “Mode” is set to “LFE”,
no sound may be output from the subwoofers,
depending on the input signal or selected
surround mode.
4
Press ENTER to enter the setting.
Bass Setting
1
Use ui to select “Bass Setting”, and
then press ENTER.
Bass Setting
LFE •120Hz–
2
Use o p to select the frequency.
LFE
Set LFE signal playback range.
• 80Hz / 90Hz / 100Hz / 110Hz / 120Hz / 150Hz
/ 200Hz / 250Hz
1
Use ui to select “Distance”, and
then press ENTER.
Distance
Feet :• 1ft–
2
Use o p to change the step (minimum
variable distance).
1ft : For changing in 1-foot steps.
0.1ft : For changing in 0.1-foot steps.
Bass Setting
Default settings are underlined.
Distance
Default settings are underlined.
3
Use ui to select a speaker, and use
o p to select distance.
FL / FR / C / SW / SL / SR / SBLz / SBRz
Select the speaker.
zWhen the “Speaker Confi g.” – “S.B(Pre)”
(vpage 7) setting is set to “None”,
“SBL” and “SBR” is not displayed.
• 0.0ft – 60.0ft : Set the distance.
• The speakers that can be selected differ
depending on the “Speaker Confi g.” (vpage7)
settings.
• Default settings :
FL / FR / C / SW : 12.0 ft
SL / SR / SBL / SBR : 10.0 ft
• Set the difference in the distance between the
speakers to less than 20 ft.
NOTE
Speakers set to “None” in “Speaker Confi g.”
(vpage7) are not displayed.
4
Press ENTER to enter the setting.
Distance
1.AVR391E3ENG4th100602.inddSec:81.AVR391E3ENG4th100602.inddSec:8 2010/06/0414:29:192010/06/0414:29:19

Denon AVR-391 Specifications

General

Number of Channels	5.1
HDMI Inputs	4
HDMI Outputs	1
Dolby Formats	Dolby Digital, Dolby Pro Logic II
Audio Return Channel	Yes
Component Video Inputs	2
Digital Optical Inputs	1
Digital Coaxial Inputs	1
Response Bandwidth	10 Hz - 100 kHz
Signal-To-Noise Ratio	98 dB
THD	0.08%
Input Impedance	47 kOhms
Input Sensitivity	200 mV
Tuner Bands	AM/FM
Power Output	75 Watts per channel
DTS Formats	DTS
Tuner Frequency Range	FM: 87.5 - 108 MHz
Video Inputs/Outputs	Composite
Audio Inputs/Outputs	Digital Optical
Dimensions	434 x 151 x 319 mm
Weight	8.5 kg
