51
AVR-4306/AVC-4320
3. OTHERS
GP1UM271XK (Remote Control Sensor) (FR: IC101)
4. OPTICAL
TORX142 (MA: IC907~910)
TOTX142 (MA: IC911, 912)
GP1FM313RZ (AV: IC916)
5. LED
SML1216W (LED) (FR: LD121, 301)
GND
Vcc
Vout
GND
VOUT
Vcc
Head
Amp
Limiter
Amp
BPF
Detector &
Comparator
Integrator
Hysteresis
Comparator
1. Vcc
2. GND
3. Vout
1
2
3
1. Vin
2. Vcc
3. GND
1
2
3
RED GREEN
