Denon AVR-4306 Service Manual

67
AVR-4306/AVC-4320
PARTS LIST OF P.W.B. UNIT
＊本表に記載されている部品は、補修用部品のため製品に使用している部品とは一部、形状、寸法などが異なる場合があります。
＊ The parts listed below are for maintenance only, might differ from the parts used in the unit in appearances or dimensions.
＊"nsp" 印の部品は常時在庫していませんので供給に長時間を要することがあります。場合によっては、供給をお断りする場合があります。
＊ Part indicated with the mark “nsp” are not always in stock and possibly to take a long period of time for supplying, or in some case supplying of part may be refused.
00D1U-3698 DIGITAL P.W.B. UNIT ASS'Y
Ref. No. nsp Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC101-103 00D 262 3449 004 LC89057W-VF4A
IC151 00D 262 3580 002 EPM570T144C5N *
IC201 00D 262 3431 012 SII9031CTU-7
IC202 00D 262 3265 903 LM1117MPX-1.8 +C
IC204 00D 262 3416 901 BR24L02F-WE2
IC251 00D GEN 8063 SUB CPU SUB ASSY M30624FGPGP
IC252 00D 262 2517 908 SN74LV08APW-EL2 +REF
IC254 00D 262 3410 907 TC74VHCT08AFT
IC301 00D 262 3069 905 PCM1804 +REF
IC302-305 00D 262 3332 904 PCM1791ADBR +REF
IC306 00D 263 1079 903 BA033FP +C
IC307-309 00D 263 0934 900 BA4510F-E2 +C
IC310-314 00D 262 3555 901 SA5532ADR
IC351,352 00D 262 3552 904 AK4385ET
IC353,354 00D 263 0615 902 BA15218F-DXE2 +C
IC401 00D 262 3431 012 SII9031CTU-7
IC402 00D 262 3265 903 LM1117MPX-1.8 +C
IC403,404 00D 262 3416 901 BR24L02F-WE2
IC471 00D 262 3364 011 SII9030CTU-7
IC472 00D 262 3265 903 LM1117MPX-1.8 +C
IC502 00D 262 3339 907 SN74LVC139APWR +REF
IC503,504 00D 262 3559 907 TC74VHC573FT
IC505 00D 262 3557 909 FCXO-03L(20.815MHZ)
IC506 00D 262 3550 003 ADSP-21366SKBCZ
IC507 00D GEN 8064 DSP ROM SUB ASSY LH28F160BJE-BTL90 +C
IC508-510 00D 262 3341 005 CY7C1049CV33-10ZC +REF
IC601 00D 262 3495 003 ADV7403BSTZ-110
IC604 00D 262 3519 905 PQ018EZ01ZPH
IC605 00D 262 2977 917 BA25BC0FP-E2
IC606 00D 263 1079 903 BA033FP +C
IC607 00D 262 3519 905 PQ018EZ01ZPH
IC608 00D 262 2977 917 BA25BC0FP-E2
IC610 00D 262 3478 004 ADV7320
IC611 00D 262 3365 900 BH7868FS
IC612,613 00D 263 1082 903 TK15420MTL +C
IC614 00D 263 1198 907 LT1399CS +REF
IC617 00D 262 3425 905 LTC4300-2CMS8
IC701 00D 262 3579 000 EPM570F256C5N *
IC751 00D 262 3577 002 FLI2310-LF-CF
IC752 00D 262 3303 001 K4S643232#-TC60 +REF
IC753 00D 262 3265 903 LM1117MPX-1.8 +C
IC754 00D 262 3553 000 LC4064V-75TN100C
IC801 00D 262 3106 907 SN65LVDS32PW +REF
IC802 00D 262 3432 901 SN65LVDS1DBVR
IC803 00D 262 3436 907 TC74VHC244FT
IC841 00D 262 3517 907 F2602-01-TR
IC842 00D 262 3516 908 FCXO-03L(45.1584MHZ)
IC843 00D 262 3410 907 TC74VHCT08AFT
IC844 00D 262 2517 908 SN74LV08APW-EL2 +REF
IC850 00D 263 1205 900 PQ012FZ01ZP +C
IC901 00D 262 3583 009 DM9161AEP *
IC902 00D 262 3522 905 MIC2025-1YM
IC903 00D GEN 8082 DM850 ROM SUB ASSY W19B320ABT7H
IC904 00D 262 3520 017 IS42S16400C1-6TL *
IC905 00D 262 3523 001 BCOIC-DM850-CQL
IC906 00D 262 3062 902 FCX0-03(24.576MHZ) +REF
IC907 00D 263 1110 901 PQ070XZ01ZP +C
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

Denon AVR-4306 Specifications

General

Receiver type	Surround
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Audio output channels	7.1 channels
Signal-to-Noise Ratio (SNR)	102 dB
Dynamic power per channel (4 Ohm)	220 W
Dynamic power per channel (8 Ohm)	150 W
Power output per channel (1KHz@6 Ohm)	170 W
Power output per channel (20-20KHz@8 Ohm)	130 W
HDMI in	3
Line-in	Yes
Composite video in	7
USB ports quantity	1
Digital audio coaxial in	2
Digital audio optical in	5
Headphone connectivity	3.5 mm
Speakers connectivity type	RCA
AC input voltage	120 V
AC input frequency	60 Hz
Power consumption (standby)	1 W
Power consumption (typical)	570 W
3D	-
Optical drive included	No
Product color	Silver
Audio decoders	DTS 96/24, DTS Neo:6, DTS-ES, Dolby Digital, Dolby Digital EX, Dolby Pro Logic IIx
Apple docking compatibility	iPod

Weight and Dimensions

Depth	429 mm
Width	434 mm
Height	171 mm
Weight	18500 g
