96
AVR-4306/AVC-4320
PARTS LIST OF EXPLODED VIEW
＊本表に記載されている部品は、補修用部品のため製品に使用している部品とは一部、形状、寸法などが異なる場合があります。
＊ The parts listed below are for maintenance only, might differ from the parts used in the unit in appearances or dimensions.
＊"nsp" 印の部品は常時在庫していませんので供給に長時間を要することがあります。場合によっては、供給をお断りする場合があります。
＊ Part indicated with the mark “nsp” are not always in stock and possibly to take a long period of time for supplying, or in some case supplying of part may be refused.
Ref. No. nsp Part No. Part Name Remarks Q'ty New
1 nsp 00D1U-3700E MAIN CPU UNIT ASS’Y 1
1-1 MAIN CPU UNIT
1-2 DIGITAL IN UNIT
1-3 EXT IN/PREOUT UNIT
1-4 PRE CONNECT2 UNIT
1-5 WIRE COVER UNIT
2 nsp 00D1U-3701E POWER AMP UNIT ASS’Y 1
2-1 POWER AMP UNIT
2-2 PRIMARY UNIT
2-3 IPOD REG UNIT
2-4 IPOD TR UNIT
2-5 FFC COVER UNIT
2-6 STYLE PIN UNIT
3 nsp 00D1U-3702E P.SUPPLY UNIT ASS’Y 1
3-1 P.SUPPLY UNIT
3-2 CONNECT UNIT
3-3 VOL AMP UNIT
3-4 PRE CONNECT UNIT
4 nsp 00D1U-3703E FRONT UNIT ASS’Y 1
4-1 FLD UNIT
4-2 FUNC. UNIT
4-3 P.KEY UNIT
4-4 JOINT UNIT
4-5 TACT-1 UNIT
4-7 VOL UNIT
4-8 P.SW UNIT
4-9 H/P UNIT
4-10 CVBS UNIT
4-11 V-CONN1 UNIT
4-12 V-CONN2 UNIT
4-13 232C UNIT
4-14 EXT.CONNECT UNIT
5 nsp 00D1U-3743 AUDIO/VIDEO UNIT ASS’Y 1 *
5-1 AUDIO UNIT
5-3 FRONT IN UNIT
5-4 MIC UNIT
5-5 COMP-VIDEO UNIT
5-6 S-VIDEO UNIT
5-7 D.LINK-43 UNIT
5-9 USB UNIT
5-10 F/IPOD UNIT
5-11 R/IPOD UNIT
6 00D1U-3698 DIGITAL UNIT ASS’Y 1 *
6-1 DIGITAL UNIT
6-2 ETHERNET UNIT
6-3 DSP UNIT
