97
AVR-4306/AVC-4320
11 nsp 00D 411 2089 025 MAIN CHASSIS 1 *
12 nsp 00D 412 5270 203 TRANS PLATE 1
13 nsp 00D 412 4210 002 BRACKET 2
14 nsp 00D 412 5273 006 R BRACKET BASE 1
15 nsp 00D 412 4716 014 SUPPORT BRACKET 1
16 nsp 00D 104 0334 007 FOOT 4
17 nsp 00D 461 0385 001 RUBBER PAD 4
18 nsp 00D 412 3548 005 P.W.B CATCHER 3
19 - RADIATOR 1
20 - CU PLATE 1
21 nsp 00D 412 4127 001 PWB BRACKET (B) 2
22 nsp 00D 412 5271 008 RADIATOR BRACKET (F) 1
23 nsp 00D 412 5272 007 RADIATOR BRACKET (R) 1
24 nsp 00D 412 2814 028 CARD SPACER(L=10) 16
25 - INSULATING SHEET(B) 1
26 nsp 00D 479 0003 038 PUSH RIVET 3
27 nsp 00D 477 0231 024 4W(S) 2
28 nsp 00D 449 0070 002 LOCKING CARD SPACER 2
29 nsp 00D 105 1654 080 BACK PANEL 1 *
30 nsp 00D 449 0202 032 LOCKING CARD SPACER 1
31 nsp 00D 205 1116 006 TERMINAL ASS 1
32 00D 216 0124 002 AM FM TUNER(E3) 1
! 33 00D 203 3996 008 AC INLET (2P) 1
! 34 00D 233 6523 013 POWER TRANS(3806E3) 1
35 nsp 00D 461 0415 007 RUBBER SHEET 2
36 - INSULATING SHEET(A) 1
37 nsp 00D 461 1227 016 RUBBER FOAM 1
38 nsp 00D 461 1182 070 RUBBER SHEET 2
40 nsp 00D 461 1182 083 RUBBER SHEET 1 *
41 nsp 00D 415 0985 000 SPACER 1 *
42 nsp 00D 461 1210 007 EMIGASKET SHSG060100 1
43 nsp 00D 513 3333 005 LABEL (TRANS) 1
44 nsp 00D 461 0573 033 RUBBER SHEET 1
45 nsp 00D GEN 8016 TOP COVER SUB ASSY for Black model 1
45 nsp 00D GEN 8016 -1 TOP COVER SUB ASSY for Silver model 1
46 nsp 00D 146 2361 001 SCREW COVER 1
47 00D 278 0013 001 DHCT-A3/C3 7
47-1 - DHCT-A3 TR103,104,203,303,304,403,404
47-2 - DHCT-C3 TR101,102,201,301,302,401,402
51 00D 146 2444 009 INNER PANEL for Black model 1
51 00D 146 2444 012 INNER PANEL for Silver model 1
52 00D 143 1216 006 DISPLAY SHEET 1
53 00D 143 1189 007 POWER LENS 1
54 00D 146 2347 203 INNER FRAME for Black model 1
54 00D 146 2347 216 INNER FRAME for Silver model 1
55 00D 146 2447 103 USB GUIDE for Black model 1 *
55 00D 146 2447 116 USB GUIDE for Silver model 1 *
56 00D 143 1236 002 DOOR SHEET for Black model 1 *
56 00D 143 1236 015 DOOR SHEET for Silver model 1 *
57 nsp 00D 461 1182 012 RUBBER SHEET 2
58 nsp 00D 461 1182 009 RUBBER SHEET 20X10X1T 2
59 00D 143 1233 306 WINDOW for Black model 1
59 00D 143 1233 319 WINDOW for Silver model 1
60 00D 113 1992 109 P.KNOB ASSY(SUB) for Black model 1
60 00D 113 1992 112 P.KNOB ASSY(SUB) for Silver model 1
Ref. No. nsp Part No. Part Name Remarks Q'ty New
