Denon AVR-591 Service Manual

125
Ref. No. Part No. Part Name Remarks Q'ty New
C6 nsp C,FILM MI-0.047UF-J/50V D020473167050S
C7 nsp C,CERAMIC 2200PF-K/50V D011222777160S
C8,9 nsp C,FILM MI-0.047UF-J/50V D020473167050S
C10 nsp C,CERAMIC 2200PF-K/50V D011222777160S
C11,12 nsp C,FILM MI-0.047UF-J/50V D020473167050S
C13 nsp C,CERAMIC 2200PF-K/50V D011222777160S
C14 nsp C,FILM MI-0.047UF-J/50V D020473167050S
C17 nsp C,FILM MI-0.047UF-J/50V D020473167050S
C27 nsp C,CERAMIC 1000PF-K/50V D011102777160S
C30 nsp C,CERAMIC 1000PF-K/50V D011102777160S
C33 nsp C,CERAMIC 1000PF-K/50V D011102777160S
C36 nsp C,CERAMIC 1000PF-K/50V D011102777160S
C39 nsp C,CERAMIC 1000PF-K/50V D011102777160S
C53 00D9609009937 C,ELECT 100UF-M/50V D040101087060S
C54 nsp C,FILM 0.1UF-K/250V D02010407H080S
C55 963134004220S C,ELECT 6800UF-M/75V D04068208A000S
C57 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C58 963134004220S C,ELECT 6800UF-M/75V D04068208A000S
C60 00D9630244606 C,ELECT 0.1UF-M/50V (Pb Free) D040R10087080S
C61 nsp C,FILM 0.1UF-K/250V D02010407H080S
C63 nsp C,CERAMIC 1000PF-K/50V D011102777160S
! C100 963132010140S C,CERAMIC ECQU2A104ML 0.1UF D00810408H000S
C102 963134010530S C,ELECT 100UF-M/400V D04110108K010S
C103 963132010120S C,CERAMIC DEHR33A102KB2B D00810207Q010S
! C104,105 963132010160S C,CERAMIC DE1B3KX471KB5B D00847107H010S
C106-108 963134010220S C,ELECT5600UF-M/6.3V D041562081001S
C110 nsp C,CERAMIC 0.1UF-K/25V D011104774161S
C111 nsp C,CERAMIC 4.7UF-K/6.3V D011475571160S
C112 963134010190S C,ELECT 10UF-M/50V D041100087050S
C113 nsp C,CERAMIC 0.1UF-K/25V D011104774161S
C115 963132010150S C,CERAMIC DE1E3KX222MB5BA01 D00822208H010S
C116 nsp C,CERAMIC 0.1UF-K/25V D011104774161S
C117 963132010130S C,CERAMIC DE2F3KH103MB3B AC250V D008103089010S
C118 nsp C,CERAMIC 0.1UF-K/25V D011104774161S
C119 963134010210S C,ELECT 47UF-M/25V D041470084050S
C120-123 nsp C,CERAMIC 0.1UF-K/25V D011104774161S
OTHERS PARTS GROUP
BKT1-3 nsp BRACKET t1.0+Sn plating /PCB MTG 4010214876000S
BKT100 nsp BRACKET 0.8t/SCREW 4010210196100S
BKT101 nsp BRACKET SCREW 4010210196000S
CLAMP3 nsp CLAMP WIRE(SOLDER) 4330000120000S
CN1 nsp CN,WIRE 230MM/5P L000231052050S
CN3 nsp CN,WIRE 2MM 170MM/10P L002171102620S
CP1 nsp CN.WAFER 3CKT L108353280360S
CP12 nsp CN.FPC 1.25MM 19P L131019100010S
CP22 nsp CN.WAFER 5P L101100040510S
CX100 nsp CN.WAFER 7.92MM L108202000220S
CX102 nsp CN.WAFER 7.92MM L108353280290S

Denon AVR-591 Specifications

General

Channels	5.1
Power Output	75 W per channel (8 ohms, 20 Hz - 20 kHz, 0.08% THD)
Frequency Response	10 Hz - 100 kHz (+1, -3 dB)
Input Sensitivity/Impedance	200 mV / 47 kohms
Signal-to-Noise Ratio	98 dB
HDMI Inputs	4
HDMI Outputs	1
Audyssey	Audyssey MultEQ
HDMI Pass-Through	Yes
Tuner Bands	AM/FM
Preset Station Qty	56
Total Harmonic Distortion	0.08%
Tuner Frequency Range	FM: 87.5 - 107.9 MHz, AM: 520 - 1710 kHz
Dolby Support	Dolby Digital, Dolby Digital Plus
DTS Support	DTS-HD Master Audio
Dimensions	434 x 167 x 382 mm
Weight	21.6 lbs (9.8 kg)
