Denon AVR-591 Service Manual

126
Ref. No. Part No. Part Name Remarks Q'ty New
CX104 nsp CN.WAFER 5P L101100030510S
CX105 CN,WIRE 370MM/5P L000371050010S
z
F100 963652010510S FUSE T2A/250V N751502001160S *
z
F101 963652010540S FUSE T5A/250V N751505001160S *
JACK1 963643010360S 6P JB-602A-02 G613602A0200YS
JACK2 00D9630257208 8P JB-405E(V0)-02 G612405E0200YS
L1-5 nsp COIL INDUCTOR 0.5UH D330R50000000S
z
L100 963111010230S COIL LINE FILTER LF-4ZB-E273H 27mH D320402730020S
z
RL101 963682010370S RELAY HL31-1AT-5H 5V 1A G680050102020S *
RLY1 00D9630218409 RELAY BC3-12 24V 2A G680240202030S
RLY2-4 963682002440S RELAY 12V 5A SPK G680120502050S
z
T100 963102010240S TRANS,SWITCHING ST-4430A E060044300010S *
nsp LABEL FUSE T5AL/250V 5507000006780S
nsp HOLDER,FUSE CLIP F100_1 G645000050010S
nsp HOLDER,FUSE CLIP F100_2 G645000050010S
nsp HOLDER,FUSE CLIP F101_1 G645000050010S
nsp HOLDER,FUSE CLIP F101_2 G645000050010S

Denon AVR-591 Specifications

General

Channels	5.1
Power Output	75 W per channel (8 ohms, 20 Hz - 20 kHz, 0.08% THD)
Frequency Response	10 Hz - 100 kHz (+1, -3 dB)
Input Sensitivity/Impedance	200 mV / 47 kohms
Signal-to-Noise Ratio	98 dB
HDMI Inputs	4
HDMI Outputs	1
Audyssey	Audyssey MultEQ
HDMI Pass-Through	Yes
Tuner Bands	AM/FM
Preset Station Qty	56
Total Harmonic Distortion	0.08%
Tuner Frequency Range	FM: 87.5 - 107.9 MHz, AM: 520 - 1710 kHz
Dolby Support	Dolby Digital, Dolby Digital Plus
DTS Support	DTS-HD Master Audio
Dimensions	434 x 167 x 382 mm
Weight	21.6 lbs (9.8 kg)
