Denon AVR-591 Service Manual

130
Ref. No. Part No. Part Name Remarks Q'ty New
C120 nsp C,CERAMIC 330PF-J/50V D010331167160S
C121 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C122 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C123 00D9630293602 C,ELECT 1UF-M/50V (Pb Free) D040010087150S
C124-126 nsp C,CERAMIC 100PF-J/50V D010101167160S
C127 nsp C,CERAMIC0.047UF-K/25V D011473774161S
C129 00D9630293602 C,ELECT 1UF-M/50V (Pb Free) D040010087150S
C130 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C131 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C132 00D9630293602 C,ELECT 1UF-M/50V (Pb Free) D040010087150S
C133 nsp C,CERAMIC 0.047UF-Z/50V D011473597160S
C134 00D9630293602 C,ELECT 1UF-M/50V (Pb Free) D040010087150S
C137 nsp C,CERAMIC 0.047UF-Z/50V D011473597160S
C139 nsp C,CERAMIC 0.01UF-K/50V D011103777162S
C142 nsp C,FILM 0.047UF-J/100V D02047306C060S
C143,144 00D9630293602 C,ELECT 1UF-M/50V (Pb Free) D040010087150S
C145 nsp C,FILM 0.047UF-J/100V D02047306C060S
C146 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C147 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C148,149 nsp C,CERAMIC 0.01UF-K/50V D011103777162S
C150 nsp C,CERAMIC 0.047UF-Z/50V D011473597160S
C151 00D9639005862 C,ELECT 47UF-M/16V D040470083080S
C152 nsp C,CERAMIC 0.047UF-Z/50V D011473597160S
C153 nsp C,FILM ST-0.01UF-J/100V D02010306C060S
C154 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C155 nsp C,FILM ST-0.01UF-J/100V D02010306C060S
C156,157 nsp C,CERAMIC 1000PF-K/50V D011102777160S
C158 nsp C,CERAMIC 0.01UF-K/50V D011103777162S
C159 nsp C,CERAMIC 0.047UF-Z/50V D011473597160S
C160 nsp C,CERAMIC 0.01UF-K/50V D011103777162S
C161 nsp C,CERAMIC 0.047UF-Z/50V D011473597160S
C165 nsp C,CERAMIC 0.01UF-K/50V D011103777162S
C166 00D9630293709 C,ELECT 100UF-M/10V D040101082070S
OTHERS PARTS GROUP
BD100-104 nsp R,THICK 0-J,1/16W C20000006M160S
BD105 nsp COIL,BEAD CBW160808U121T D340160811210S
BD106-109 nsp R,THICK 0-J,1/16W C20000006M160S
CB100,101 nsp R,THICK 0-J,1/16W C20000006M160S
CLAMP111 nsp CLAMP WIRE(SOLDER) 4330000120000S
CLAMP114 nsp CLAMP WIRE(SOLDER) 4330000120000S
CLAMP116 nsp CLAMP WIRE(SOLDER) 4330000120000S
CN100 nsp CN,WIRE 2MM 130MM/5P L002131050010S *
CP100 nsp CN.WAFER 5P L101200100510S
CP100_1 nsp 5268-07A 7P ANGLE L102526800700S
CP102 nsp CN.WAFER 2.0MM 8P L101100030810S
CP103,104 nsp CN.WAFER 8P L101100040810S

Denon AVR-591 Specifications

General

Channels	5.1
Power Output	75 W per channel (8 ohms, 20 Hz - 20 kHz, 0.08% THD)
Frequency Response	10 Hz - 100 kHz (+1, -3 dB)
Input Sensitivity/Impedance	200 mV / 47 kohms
Signal-to-Noise Ratio	98 dB
HDMI Inputs	4
HDMI Outputs	1
Audyssey	Audyssey MultEQ
HDMI Pass-Through	Yes
Tuner Bands	AM/FM
Preset Station Qty	56
Total Harmonic Distortion	0.08%
Tuner Frequency Range	FM: 87.5 - 107.9 MHz, AM: 520 - 1710 kHz
Dolby Support	Dolby Digital, Dolby Digital Plus
DTS Support	DTS-HD Master Audio
Dimensions	434 x 167 x 382 mm
Weight	21.6 lbs (9.8 kg)
