Denon AVR-591 Service Manual

131
Ref. No. Part No. Part Name Remarks Q'ty New
CP105 nsp CN.WAFER 2.0MM 8P L101100030810S
G101 nsp RING,TER WIRE 100MM/1P 8410101010240S
JACK100 00D9630367802 JACK,D3.5 EARPHONE G401PJ354H40YS
JACK102 00D9630146403 TER,RCA 3PIN G606308HG110YS
JK100 00D9630294708 JACK,D6.5 PHONE G402PJ612AG0YS
L100 nsp COIL INDUCTOR 100UH D330101001020S
RMC100 963262010290S MODULE,REMOCON R34FS9A E940349003810S
SW100-123 00D9630095305 SW,TACT SKHV10910D01 G180040500010S
VEC100,101 00D9630387408 SW,ENCODER EC16B24SO G121162400070S
U1 nsp CN.FPC 1.0MM 1.0-11S-40PW 40P L130100114050S *
U100 963172010470S DISPLAY,FLT 18-ST-13GINK K530180130010S
JP210-213 nsp R,CHIP 0-J,1/8W C200000061300S
nsp HOLDER FLT 4320200026000S

Denon AVR-591 Specifications

General

Channels	5.1
Power Output	75 W per channel (8 ohms, 20 Hz - 20 kHz, 0.08% THD)
Frequency Response	10 Hz - 100 kHz (+1, -3 dB)
Input Sensitivity/Impedance	200 mV / 47 kohms
Signal-to-Noise Ratio	98 dB
HDMI Inputs	4
HDMI Outputs	1
Audyssey	Audyssey MultEQ
HDMI Pass-Through	Yes
Tuner Bands	AM/FM
Preset Station Qty	56
Total Harmonic Distortion	0.08%
Tuner Frequency Range	FM: 87.5 - 107.9 MHz, AM: 520 - 1710 kHz
Dolby Support	Dolby Digital, Dolby Digital Plus
DTS Support	DTS-HD Master Audio
Dimensions	434 x 167 x 382 mm
Weight	21.6 lbs (9.8 kg)
