56
DSP surround simulation
1
Select the surround mode for the input channel.
• To operate the surround mode and surround parameters from the remote control unit.
The surround mode switches in the following order each time the DSP
SIMULATION button is pressed:
2
Display the surround parameter screen on the monitor.
The screen for the selected surround mode appears.
3
Set the parameters.
4
To end the setting mode, press the surround parameter button again.
(Remote control unit)
(Remote control unit)
(Remote control unit)
(Remote control unit)
NOTES:
• When “Default” is selected and the 0 courser button is pressed, “CINEMA EQ.” and “D.COMP.” are automatically turned off, “ROOM
SIZE” is set to “medium”, “EFFECT LEVEL” to “10”, “DELAY TIME” to “30ms” and “LFE” to “0dB”.
• The “ROOM SIZE” expresses the expansion effect for the different surround modes in terms of the size of the sound field, not the actual
size of the listening room.
