Denon AVR-E300 User Manual

113
Display
r etyuioQ0
q w
q Information display
The input source name, sound mode, setting values and other
information are displayed here.
w Input signal indicators
e MUTE indicator
This lights when the audio mute mode is selected (vpage28).
r Master volume indicator
t Circle indicator
Circle indicator is displayed when the input source is “NETWORK”
or “iPod/USB” when you are playing back music.
y Sleep timer indicator
This lights when the sleep mode is selected (vpage79).
u Tuner reception mode indicators
These light according to the reception conditions when the input
source is set to “TUNER”.
STEREO : In FM mode, this lights up when receiving stereo
broadcasts.
TUNED : Lights up when the broadcast is properly tuned in.
i Audyssey
®
indicator
This indicator lights when the “MultEQ
®
” (vpage89), “Dynamic
EQ” (vpage 90) or “Dynamic Volume” (vpage 90) setting
is set to other than “O”.
o Decoder indicator
These light when Dolby or DTS signals are input or when the Dolby
or DTS decoder is running.
Q0 Input mode indicators
Set the audio input modes for the dierent input sources
(vpage97).
Basic instructions
Advanced instructions
InformationInformation
DVD

Denon AVR-E300 Specifications

General

Channels	5.1
HDMI Inputs	4
HDMI Outputs	1
3D Pass-through	Yes
Audio Return Channel (ARC)	Yes
Dolby TrueHD	Yes
DTS-HD Master Audio	Yes
Networking	No
AirPlay	No
Audyssey MultEQ	Yes
HDMI Pass-Through	Yes
Receiver Type	AV Receiver
HDMI Ports Quantity	5
Audio DAC	192 kHz / 24-bit
Digital Sound Processor (DSP)	Yes
Input Sensitivity	200 mV
Response Bandwidth	10 Hz - 100 kHz
Signal-To-Noise Ratio	98 dB
Tuner Bands	AM/FM
Amplifier Type	Discrete
Frequency Response	10 Hz - 100 kHz
Bluetooth	No
Wi-Fi	No
Output Power / Total	375 W
Input Impedance	47 kOhms
Video Inputs/Outputs	Composite
Audio Inputs/Outputs	Digital Optical
Power Output per Channel	75 W (8 ohms, 20 Hz - 20 kHz, 0.08% THD)
Power Output	75W (8 ohms, 20 Hz - 20 kHz, 0.08% THD, 2 channels driven)
