Denon AVR-E300 User Manual

39
Listening to FM/AM broadcasts
n Changing the tuning mode (Tune Mode)
You can change the mode for tuning into FM broadcasts. If you
cannot tune in automatically with “Auto” mode, then change the
mode to “Manual” and tune in manually.
1
Press TUNER to switch the input
source to “TUNER”.
2
Press OPTION.
The option menu screen is displayed.
3
Use ui to select “Tune Mode”,
then press ENTER.
GTV ScreenH
TUNE+/- OPTION
AUTO
CH+/-
CH 1
FM 92.10MHz
Tune Preset Option
TUNER
FM/AM
Option
Direct Tune
Preset Memory
Tune Mode
Auto Preset
Preset Name
Preset Skip
Video Select
GDisplay of this unitH
Tune Mode
4
Use o p to select tuning mode, then press ENTER.
GTV ScreenH
Auto
Tune Mode
GDisplay of this unitH
Mode :• Auto –
Auto
Automatically tune to the station.
Manual
Manually tune to the station.
When tuning in stations manually, press and hold TUNE + or TUNE– to
change frequencies continuously.
Basic instructions
Advanced instructions
Information
Basic instructions
DVD

Denon AVR-E300 Specifications

General

Channels	5.1
HDMI Inputs	4
HDMI Outputs	1
3D Pass-through	Yes
Audio Return Channel (ARC)	Yes
Dolby TrueHD	Yes
DTS-HD Master Audio	Yes
Networking	No
AirPlay	No
Audyssey MultEQ	Yes
HDMI Pass-Through	Yes
Receiver Type	AV Receiver
HDMI Ports Quantity	5
Audio DAC	192 kHz / 24-bit
Digital Sound Processor (DSP)	Yes
Input Sensitivity	200 mV
Response Bandwidth	10 Hz - 100 kHz
Signal-To-Noise Ratio	98 dB
Tuner Bands	AM/FM
Amplifier Type	Discrete
Frequency Response	10 Hz - 100 kHz
Bluetooth	No
Wi-Fi	No
Output Power / Total	375 W
Input Impedance	47 kOhms
Video Inputs/Outputs	Composite
Audio Inputs/Outputs	Digital Optical
Power Output per Channel	75 W (8 ohms, 20 Hz - 20 kHz, 0.08% THD)
Power Output	75W (8 ohms, 20 Hz - 20 kHz, 0.08% THD, 2 channels driven)
