Denon AVR-E300 User Manual

41
Listening to FM/AM broadcasts
n Specify a name for the preset broadcast station
(Preset Name)
You can set the name to the preset broadcast station or change it.
Up to eight characters can be input.
1
Press TUNER to switch the input source to “TUNER”.
2
Press OPTION.
The option menu screen is displayed.
3
Use ui to select “Preset Name”,
then press ENTER.
The Preset Name screen is displayed.
GTV ScreenH
TUNE+/- OPTION
AUTO
CH+/-
CH 1
FM 92.10MHz
Tune Preset Option
TUNER
FM/AM
Option
Direct Tune
Preset Memory
Tune Mode
Auto Preset
Preset Name
Preset Skip
Video Select
GDisplay of this unitH
Preset Name
4
Use o p to select the group of the broadcast station
you want to name then press ENTER.
The screen that lets you edit the preset name is displayed.
•Each time
o p is pressed, the setting is changed as shown below.
1 – 8 9 – 16 25 – 3217 – 24
41 – 4849 – 56 33 – 40
GTV ScreenH
CH 3 FM 92.50MHz
CH 2 FM 92.30MHz
CH 1 FM 92.10MHz
Preset Group
CH 6 FM 93.50MHz
CH 5 FM 93.10MHz
CH 8 FM 94.10MHz
CH 7 FM 93.70MHz
CH 4 FM 92.70MHz
Preset Name
1-8
GDisplay of this unitH
Group :• 1- 8–
5
Use ui to select the broadcast station you want to
name, then press ENTER.
GTV ScreenH
Preset Name
CH 1 FM 92.10MHz
Set Defaults
GDisplay of this unitH
1 FM 92.10MHz
6
Use ui to select a name label, then press ENTER.
The screen that lets you edit the preset name is displayed.
•If you select “Set Defaults”, then the unit returns to displaying the
frequency.
7
Enter the characters, then press
OK
.
•For character input, see page84.
8
Press BACK twice.
The display returns to the playback screen.
Basic instructions
Advanced instructions
Information
Basic instructions
DVD

Denon AVR-E300 Specifications

General

Channels	5.1
HDMI Inputs	4
HDMI Outputs	1
3D Pass-through	Yes
Audio Return Channel (ARC)	Yes
Dolby TrueHD	Yes
DTS-HD Master Audio	Yes
Networking	No
AirPlay	No
Audyssey MultEQ	Yes
HDMI Pass-Through	Yes
Receiver Type	AV Receiver
HDMI Ports Quantity	5
Audio DAC	192 kHz / 24-bit
Digital Sound Processor (DSP)	Yes
Input Sensitivity	200 mV
Response Bandwidth	10 Hz - 100 kHz
Signal-To-Noise Ratio	98 dB
Tuner Bands	AM/FM
Amplifier Type	Discrete
Frequency Response	10 Hz - 100 kHz
Bluetooth	No
Wi-Fi	No
Output Power / Total	375 W
Input Impedance	47 kOhms
Video Inputs/Outputs	Composite
Audio Inputs/Outputs	Digital Optical
Power Output per Channel	75 W (8 ohms, 20 Hz - 20 kHz, 0.08% THD)
Power Output	75W (8 ohms, 20 Hz - 20 kHz, 0.08% THD, 2 channels driven)
