Denon AVR-E300 User Manual

93
Video
On Screen Disp.
Default settings are underlined.
Select the on-screen display user interface preferences.
Setting items Setting details
Volume
Sets where to display the
master volume level.
Bottom : Display at the bottom.
Top : Display at the top.
O : Turn display o.
When the master volume display is hard to see when superimposed
text (closed captioning) or movie subtitles are present, set to “Top”.
Info
Displays status of operation
temporarily when the sound
mode is changed, or input
source is switched. You
can set whether or not to
show each of these status
displays.
On : Turn display on.
O : Turn display o.
Now Playing
Sets how long each menu
is displayed when the input
source is “NETWORK”,
“iPod/USB” or “TUNER”.
Always On : Show display continuously.
Auto O : Show display for 30 seconds after operation.
TV Format
Default settings are underlined.
Set the video signal format to be output for the TV you are using.
Setting items Setting details
Format
NTSC : Select NTSC output.
PAL : Select PAL output.
“Format” can also be set by the following procedure. However, the menu
screen is not displayed.
1. Press and hold the main unit’s TUNER PRESET CH + and STATUS for at
least 3 seconds.
“< NTSC >” appears on the display.
2. Use the main unit’s SOURCE SELECT 0 1 and set the video signal
format.
3. Press the main unit’s STATUS to complete the setting.
NOTE
When a format other than the video format of the connected TV is set, the
picture will not be displayed properly.
Basic instructions
Advanced instructions
Information
Advanced instructions
DVD

Denon AVR-E300 Specifications

General

Channels	5.1
HDMI Inputs	4
HDMI Outputs	1
3D Pass-through	Yes
Audio Return Channel (ARC)	Yes
Dolby TrueHD	Yes
DTS-HD Master Audio	Yes
Networking	No
AirPlay	No
Audyssey MultEQ	Yes
HDMI Pass-Through	Yes
Receiver Type	AV Receiver
HDMI Ports Quantity	5
Audio DAC	192 kHz / 24-bit
Digital Sound Processor (DSP)	Yes
Input Sensitivity	200 mV
Response Bandwidth	10 Hz - 100 kHz
Signal-To-Noise Ratio	98 dB
Tuner Bands	AM/FM
Amplifier Type	Discrete
Frequency Response	10 Hz - 100 kHz
Bluetooth	No
Wi-Fi	No
Output Power / Total	375 W
Input Impedance	47 kOhms
Video Inputs/Outputs	Composite
Audio Inputs/Outputs	Digital Optical
Power Output per Channel	75 W (8 ohms, 20 Hz - 20 kHz, 0.08% THD)
Power Output	75W (8 ohms, 20 Hz - 20 kHz, 0.08% THD, 2 channels driven)
