Denon AVR-S910W Service Manual

+20dB
+10dB
0dB
-20dB
-30dB
-40dB
-10dB
+20dB
+10dB
0dB
-20dB
-30dB
-40dB
-10dB
0dBFS
1.41Vrms
AVR-S910W/X2200W
LEVEL DIAGRAM
SURR.BACK ch
0dBFS
-10dBFS
-20dBFS
-30dBFS
-40dBFS
-29dBFS(A/D IN)
200mV
+30dB
SP OUT
4.48Vrms/8Ω
+
26dB
-
2+3+6=+7dB
N
ON CLICP MAX SIGNAL LEVEL 4.0Vrms
Config2 DOLBY LIMIT LEVEL 1.41Vrms(ALLch-3dBFS)
+3dB
-26dBFS(DIG.IN)
DD EX Config1
-
2+3=1dB
DOLBY LIMIT LEVEL 1.41Vrms(ALLch-3dBFS)
SP OUT(D/A OUT)
-32.5dBFS(DIG.IN)
DD EX Config2
INPUT : -23dBFS(DIG.IN) D.D
-2+6.5+3=7.5dB
INPUT : 200mV(A/D IN)
Mch STEREO
＋
＋
SPEAKER
DSP
BD34704
GAIN
PCM1690
D/A
－
－
＋
PLD
102

Denon AVR-S910W Specifications

General

Receiver type	Surround
Audio output channels	7.2 channels
Power output per channel (1KHz@6 Ohm)	185 W
Power output per channel (20-20KHz@8 Ohm)	- W
HDMI in	8
Composite video in	2
Digital audio coaxial in	1
Wi-Fi	Yes
AM band range	520 - 1710 kHz
FM band range	87.5 - 107.9 MHz
Supported radio bands	AM, FM
Internet radio services supported	Pandora, SIRIUS Internet Radio, Spotify
Optical drive included	No
Display	-
Product color	Black
Audio decoders	Dolby Surround, Dolby TrueHD
AC input voltage	120 V
Power consumption (standby)	0.1 W
Power consumption (typical)	500 W
Audio formats supported	AAC, ALAC, FLAC, MP3, WAV, WMA

Weight and Dimensions

Depth	337.82 mm
Width	434.34 mm
Height	167.64 mm
Weight	9389 g
