Denon AVR-S910W Service Manual

NO
NO
NO
Is IC4140 (TOP268VG) damaged?
Is D4142, D4143, D4144, D4145 or
IC4140 damaged?
Repair the short circuited area on the
PCB.
Check the damaged parts.
Replace the damaged part.
Replace the damaged part.
Is the fuse (F4140) functioning proper-
ly?
Are there any short circuits caused by
the soldering on the PCB?
Are any parts damaged?
Replace the IC4140 (TOP268VG) and
D4142 / D4143 /D4144 / D4145.
DC 5V is not output.
YES
YES
YES
YES
YES
YES
6. SMPS
95

Denon AVR-S910W Specifications

General

Receiver type	Surround
Audio output channels	7.2 channels
Power output per channel (1KHz@6 Ohm)	185 W
Power output per channel (20-20KHz@8 Ohm)	- W
HDMI in	8
Composite video in	2
Digital audio coaxial in	1
Wi-Fi	Yes
AM band range	520 - 1710 kHz
FM band range	87.5 - 107.9 MHz
Supported radio bands	AM, FM
Internet radio services supported	Pandora, SIRIUS Internet Radio, Spotify
Optical drive included	No
Display	-
Product color	Black
Audio decoders	Dolby Surround, Dolby TrueHD
AC input voltage	120 V
Power consumption (standby)	0.1 W
Power consumption (typical)	500 W
Audio formats supported	AAC, ALAC, FLAC, MP3, WAV, WMA

Weight and Dimensions

Depth	337.82 mm
Width	434.34 mm
Height	167.64 mm
Weight	9389 g
