Denon AVR-S910W Service Manual

Pin Pin Name Symbol
I/O Pu/Pd STBY STOP
CEC
STBY
Function
144
PG1 DIR DOUT
I DA3.3Pu I I I
DIR control pin(PCM9211)
145
PD6/IRQ6/AN106 DIR CLK
O L L L
DIR control pin(PCM9211)
146
PG0 DIR RST
O L L L
DIR control pin(PCM9211)
147
PD5/IRQ5/AN113 788_2_HAINT
I - Z -
HDMI MN864788(RX) Audio INT input pin
148
PD4/IRQ4/AN112 NC
I I L I
Unused
149
P97 DE_RST
O Pd Z L
HDMI ADV7850 RESET control pin
150
PD3/IRQ3/AN111 788_1_HINT
I - Z -
HDMI MN864788(TX) HDMI INT input pin
151
VSS VSS
- - - -
GND
152
P96 788_1_RST
O Pd Z
※
HDMI MN864788(TX) RESET control pin
153
VCC VCC
- - - -
POWER pin
154
PD2/IRQ2/AN110 788_2_HINT
I - Z -
HDMI MN864788(RX) HDMI INT input pin
155
P95 788_2_RST
O Pd Z
※
HDMI MN864788(RX) RESET control pin
156
PD1/IRQ1/AN109 788_3_HINT
I - Z -
HDMI MN864788(RX) HDMI INT input pin
157
P94 788_3_RST
O Pd Z
※
HDMI MN864788(RX) RESET control pin
158
PD0/IRQ0/AN108 TX EN
O L L L
Front HDMI INPUT (AD8195) control pin
159
P93/AN117 THERMAL A
I SW3VPu I L I
HEAT PROTECT-A detection pin(P.TR)
160
P92/RXD7/AN116 THERMAL B
I SW3VPu I L I
HEAT PROTECT-A detection pin(P.TR)
161
P91/AN115 NC
I - I I I
NC
162
VSS VSS
- - - -
GND
163
P90/TXD7/AN114 THERMAL E
I SW3VPu I L I
HEAT PROTECT-A detection pin(Heat Sink)
164
VCC VCC
- - - -
POWER pin
165
P47/IRQ15-DS/AN007 788_3_HAINT
I - Z -
HDMI MN864788(RX) Audio INT input pin
166
P46/IRQ14-DS/AN006 CURRENT DET
I/O I/L L/L I/L
AMP CURRENT detection pin
167
P45/IRQ13-DS/AN005 AMPSIGDET
I I L I
AMP SIGNAL detection pin
168
P44/IRQ12-DS/AN004 MODE
I I I I
Destination detection pin
169
P43/IRQ11-DS/AN003 KEY3
I M3VPu I I I
Button input 3
170
P42/IRQ10-DS/AN002 KEY2
I M3VPu I I I
Button input 2
171
P41/IRQ9-DS/AN001 KEY1
I M3VPu I I I
Button input 1
172
VREFL0 VREFL0
- - - -
GND
173
P40 MIC DET
I I I I
MIC detection detection pin
174
VREFH0 VREFH0
- - - -
POWER pin
175
AVCC0 AVCC0
- - - -
POWER pin
176
P07/IRQ15 H/P DET
I I I I
Headphone detection detection pin
147

Denon AVR-S910W Specifications

General

Receiver type	Surround
Audio output channels	7.2 channels
Power output per channel (1KHz@6 Ohm)	185 W
Power output per channel (20-20KHz@8 Ohm)	- W
HDMI in	8
Composite video in	2
Digital audio coaxial in	1
Wi-Fi	Yes
AM band range	520 - 1710 kHz
FM band range	87.5 - 107.9 MHz
Supported radio bands	AM, FM
Internet radio services supported	Pandora, SIRIUS Internet Radio, Spotify
Optical drive included	No
Display	-
Product color	Black
Audio decoders	Dolby Surround, Dolby TrueHD
AC input voltage	120 V
Power consumption (standby)	0.1 W
Power consumption (typical)	500 W
Audio formats supported	AAC, ALAC, FLAC, MP3, WAV, WMA

Weight and Dimensions

Depth	337.82 mm
Width	434.34 mm
Height	167.64 mm
Weight	9389 g
