Denon AVR-S910W Service Manual

MAIN
REF No. Part No. Part Name Remarks Q'ty New Ver
C4023 963133502350S MI-0.047UF-J/100V-5RE HMM473J2AP050T DAEHUNG D02047316C250S 1 *
C4025 963133502350S MI-0.047UF-J/100V-5RE HMM473J2AP050T DAEHUNG D02047316C250S 1 *
C4027 nsp X7R)1000PF-K/50V-1608REEL E3, E1C, JP, S910 D011102777160S 1
C4027 nsp X7R)0.1UF-K/50V-1608REEL E2 D011104577160S 1
C4030 963133502350S MI-0.047UF-J/100V-5RE HMM473J2AP050T DAEHUNG D02047316C250S 1 *
C4032 nsp X7R)1000PF-K/50V-1608REEL E3, E1C, JP, S910 D011102777160S 1
C4032 nsp X7R)0.1UF-K/50V-1608REEL E2 D011104577160S
C4035 nsp X7R)1000PF-K/50V-1608REEL E3, E1C, JP, S910 D011102777160S 1
C4035 nsp X7R)0.1UF-K/50V-1608REEL E2 D011104577160S
C4038 nsp X7R)1000PF-K/50V-1608REEL E3, E1C, JP, S910 D011102777160S 1
C4038 nsp X7R)0.1UF-K/50V-1608REEL E2 D011104577160S
C4041 nsp X7R)1000PF-K/50V-1608REEL E3, E1C, JP, S910 D011102777160S 1
C4041 nsp X7R)0.1UF-K/50V-1608REEL E2 D011104577160S
C4044 nsp X7R)1000PF-K/50V-1608REEL E3, E1C, JP, S910 D011102777160S 1
C4044 nsp X7R)0.1UF-K/50V-1608REEL E2 D011104577160S
C4047 nsp X7R)1000PF-K/50V-1608REEL E3, E1C, JP, S910 D011102777160S 1
C4047 nsp X7R)0.1UF-K/50V-1608REEL E2 D011104577160S
C4049 00D2544574922 100UF-M/50V,8*11.5-5RE.SMS SY D040101087060S 1
C4050,4051 963133502370S ST-0.1UF-J/100V-5RE HPR104J2AP050T DAEHUNG D02110406C250S 2 *
C4052 963133502010S 10000UF-M/69V,35*45 DL LKSF2103MESBZT NICHICON E3, E1C, JP, S910 D04010308Z560S 1
C4052 963134010180S 12000UF-M/71V,35*60 E2 D040123089550S
C4053 00D2544573981 10UF-M/50V,5*11-5RE.SMS SY D040100087070S 1
C4054 963133502010S 10000UF-M/69V,35*45 DL LKSF2103MESBZT NICHICON E3, E1C, JP, S910 D04010308Z560S 1
C4054 963134010180S 12000UF-M/71V,35*60 E2 D040123089550S
C4057 963133502380S MI-0.1UF-J/100V-5RE HMM104J2AP050T DAEHUNG D02010416C250S 1 *
C4059 963134011290S 4700UF-M/16V,16*25-L.BLK SMS 5.0MC SY D040472083020S 1
C4060,4061 00D2544573981 10UF-M/50V,5*11-5RE.SMS SY D040100087070S 2
C4062 00D9630217002 3300UF-M/16V,12.5*25L.BLK SHL 5.0MC SY D040332083010S 1
C4063 00D2544573981 10UF-M/50V,5*11-5RE.SMS SY D040100087070S 1
C4064 963134502380S 470UF-M/50V,12.5*20L BULK 5.0MC SMS SY D040471087010S 1
C4065 90M-OA000500R 4700UF-M/25V(MHA),16*25 P=7.5 L.BLK D040472084240S 1
C4066 963134502390S 470UF-M/50V,10*20 BULK SHL SY D040471087040S 1
C4067 90M-OA000500R 4700UF-M/25V(MHA),16*25 P=7.5 L.BLK D040472084240S 1
C4068 963134502390S 470UF-M/50V,10*20 BULK SHL SY D040471087040S 1
C4069 nsp X7R)0.1UF-K/50V-1608REEL D011104577160S 1
C4071 00D2544573981 10UF-M/50V,5*11-5RE.SMS SY D040100087070S 1
C4074 nsp COG)10PF-J/50V-1608REEL D010100167161S 1
C4075 00D9630333203 100UF-M/16V,5*11-5RE,SHL SY D040101083090S 1
C4080,4081 nsp COG100PF-J/50V-1608REEL D010101167160S 2
C4082 nsp X7R)0.1UF-K/50V-1608REEL D011104577160S 1
C4083 nsp COG100PF-J/50V-1608REEL D010101167160S 1
C4085,4086 nsp X7R)0.1UF-K/50V-1608REEL D011104577160S 2
C4087-4089 00D9609010625 1UF-M/100V,5*11-5RE.SMS SY D040010086060S 3
C4200,4201 nsp COG330PF-J/50V-1608REEL E3, E2, E1C, JP D010331167160S 2
C4202,4203 00D9630224503 22UF-M/50V,5*11-5RE.SMS SY E3, E2, E1C, JP D040220087060S 2
C4204 nsp COG330PF-J/50V-1608REEL D010331167160S 1
C4205,4206 00D9630224503 22UF-M/50V,5*11-5RE.SMS SY D040220087060S 2
C4207 nsp X7R)0.01UF-K/50V-1608REEL S910 D010103777160S 1
C4208 nsp X7R)0.01UF-K/50V-1608REEL E3, E2, E1C, JP D010103777160S 1
C4209 nsp COG330PF-J/50V-1608REEL D010331167160S 1
C4210,4211 00D9630224503 22UF-M/50V,5*11-5RE.SMS SY D040220087060S 2
C4221,4222 00D9630224503 22UF-M/50V,5*11-5RE.SMS SY E3, E2, E1C, JP D040220087060S 2
C4720-4727 nsp COG330PF-J/50V-1608REEL D010331167160S 8
OTHER PARTS GROUP
BD4000 nsp CB03YTYN121-1608REEL D340160891210S 1
BKT4143 nsp AVRX2200WBKE3(DENON) SECC t1.0+Sn plating /PCB MT 4010214876000SV 1 *
CLP4002 nsp HMX9800(ON)(HAITAI) (W=2.6,L=50)/WIRE(SOLDER) 4330000120000S 1
CN4211 nsp 260MM/3P YMH025-03=CKM2509HV-03 RD1569#22 105C L000261030130S 1 *
CN4212 nsp 120MM/10P 20010HS-10=CKM2002HV-10 WH1007#26 L002121102620S 1
CN4213 nsp 220MM/5P YMH025-05=CKM2509HV-05 RD1569#22 105C L000221050080S 1 *
CN4704 nsp 1.25B-2-23Y 23P BtoB SOCKET(FEMALE) P=1.25MM L109125422310S 1
CP4001 nsp LWB1143-07P 7.92MM HEADER,VER,7CKT L108011430710S 1
CP4002 nsp 1.25B-2-15A 15P BtoB HEADER(MALE) P=1.25MM L109125321510S 1
CP4003 nsp 1.25B-2-19A 19P BtoB HEADER(MALE) P=1.25MM L109125321910S 1 *
CP4006 nsp 1.25B-2-11A 11P BtoB HEADER(MALE) P=1.25MM L109125321110S 1
CP4007 nsp 1.25B-2-9A 9P BtoB HEADER(MALE) P=1.25MM L109125320910S 1
CP4700 nsp 1.25B-2-7A 7P BtoB HEADER(MALE) P=1.25MM E3 L109125320710S 1
CP4702 nsp 1.25B-2-7A 7P BtoB HEADER(MALE) P=1.25MM E3 L109125320710S 1
! F4000 963652010520S T6.3A/250V-IVBSUCPCcUR S506 N751506301160S 1
F4000A nsp PI5.2-REEL G645000050010S 1
F4000B nsp PI5.2-REEL G645000050010S 1
! F4001 963652010520S T6.3A/250V-IVBSUCPCcUR S506 N751506301160S 1
F4001A nsp PI5.2-REEL G645000050010S 1
F4001B nsp PI5.2-REEL G645000050010S 1
J4124 nsp JUMPER (0.6/52MM) E3 L045084006040S 1
JACK4000-4006 963646100520S SJ2003S-A006-00A200B(RD,BK) BINDING G6112003SA00JS 7
JK4200,4201 00D9630132103 RCA-405B-04(WH,WH,RD,RD)-YUQIU G602405B0400YS 2
JK4202 963643102820S RCA-405B0-02-25(WH,BK/RD,BK) E3, E2, E1C, JP G602405B0225YS 1
JK4203 963643102810S RCA-207AE-06(BK,BK) S910 G601207AE060YS 1
L4000-4006 nsp SP-2507 1.0 PI*2UEW TURNS=7T SPRING COIL D330900001330S 7
PACK4000 963183100620S KST-MW004MV1-S78SA-1 4GANG+MW+50US NA E3, S910 E903004102780S 1 *
PACK4000 963183100610S KST-MW104MV1-S78GA-1 4GANG+MW+50US RDS E2 E903104102780S 1 *
PACK4000 963183100630S KST-MW004MV1-S78A-1 4GANG+MW+50US NA IFT_VENA E1C, JP E903004100781S 1 *
RLY4000 963682100560S HFD27/012-S 24V 2A 2회로 2접점(SMALL SIGNAL) G680240202080S 1 *
RLY4001-4004 963682100280D JZC-42F/012-2HST 24.4*12.8*24.8mm G680060103010S 4
RLY4005 963682100510S HF115F/012-2ZS4B G680060083010S 1
2

Denon AVR-S910W Specifications

General

Receiver type	Surround
Audio output channels	7.2 channels
Power output per channel (1KHz@6 Ohm)	185 W
Power output per channel (20-20KHz@8 Ohm)	- W
HDMI in	8
Composite video in	2
Digital audio coaxial in	1
Wi-Fi	Yes
AM band range	520 - 1710 kHz
FM band range	87.5 - 107.9 MHz
Supported radio bands	AM, FM
Internet radio services supported	Pandora, SIRIUS Internet Radio, Spotify
Optical drive included	No
Display	-
Product color	Black
Audio decoders	Dolby Surround, Dolby TrueHD
AC input voltage	120 V
Power consumption (standby)	0.1 W
Power consumption (typical)	500 W
Audio formats supported	AAC, ALAC, FLAC, MP3, WAV, WMA

Weight and Dimensions

Depth	337.82 mm
Width	434.34 mm
Height	167.64 mm
Weight	9389 g
