Paths to be conrmed Display Settings What to conrm
6
Analog Amp Assign
(Amp Assign : ZONE2)
A 0 7 : A S S I G N - Z 2
Input Source : CBL/SAT
Input Mode : Auto
Sound mode : STEREO
Z2 Source : Source
Vol 60dB
Amp assign : ZONE2
MAIN ZONE : ON
ZONE2 : ON
・ Analog input ⇒ Speaker output (Surround Back (ZONE2) L/R)
・ Analog input ⇒ Pre OUT output (ZONE2 L/R)
(
b
The input source can be switched to any source except CBL/SAT.)
(
b
Volume 60dB is the value when Relative settings are used. The value is -20 when Absolute settings are used)
3.4.5. Conrmation items for the video system
See the block diagram g.XXth.
Paths to be conrmed Display Settings What to conrm
1
Analog Video pass
V 0 1 : V I D E O P A S S
Input Source : CBL/SAT
Video Convert (IP Scaler) : OFF, All sources
MAIN ZONE ON
ZONE2 ON
・ Component input ⇒ Component output (S910 / X2200E3 ONLY)
(
b
The input source can be switched to any source except CBL/SAT.)
2
Video Convert
(Analog or HDMI ⇒ HDMI)
V 0 2 : V . C O N V E R T
Input Source : CBL/SAT
Video Convert (IP Scaler) : ON, All sources
IP Scaler : "Analog & HDMI", All sources
Resolution : "Auto", All sources
MAIN ZONE ON
ZONE2 OFF
・ CVBS input ⇒ IP Scaler ⇒ HDMI output.
・ Component input ⇒ IP Scaler ⇒ HDMI output.
・ HDMI input ⇒ IP Scaler ⇒ HDMI output.
・ ETHERNET input ⇒ IP Scaler ⇒ HDMI output.
(
b
The input source can be switched to any source except CBL/SAT.)
3
HDMI pass
(MAIN ZONE)
V 0 3 : H D M I P A S S
Input Source : CBL/SAT
Video Convert (IP Scaler) : OFF, All sources
MAIN ZONE ON
ZONE2 OFF
・ HDMI input (MAIN function) ⇒ HDMI output(MAIN).
(
b
The input source can be switched to any source except CBL/SAT.)
4
HDMI CEC
(Control Monitor : HDMI Monitor1)
V 0 4 : H D M I C E C
Input Source : CBL/SAT
HDMI Control : ON
Control Monitor : Monitor1 (if checking the HDMI Monitor Out1)
MAIN ZONE ON
ZONE2 OFF
・ When the power supply of a TV is put in the standby mode, make sure that the power supply of this unit is also put in the
standby mode.
(
b
The input source can be switched to any source except CBL/SAT.)
・ The ARC path can also be checked (check this using the TV input source).
5
HDMI Audio
(Audio : AVR)
V 0 5 : H . A U D I O - A V R
Input Source : CBL/SAT
HDMI Control : OFF
HDMI Audio : AVR (if checking the audio output from AVR)
・ HDMI input (PCM , DolbyDigital , DTS) ⇒ Speaker output.
・ HDMI input(HD audio) ⇒ Speaker output.
(
b
The input source can be switched to any source except CBL/SAT.)
6
HDMI Audio
(Audio : TV)
V 0 6 : H . A U D I O - T V
HDMI Audio : TV (if checking the audio output from TV) ・ HDMI input (PCM , DolbyDigital , DTS) ⇒ HDMI output (audio output from connected TV)
(
b
The input source can be switched to any source except CBL/SAT.)
7
GUI
V 0 7 : G U I M E N U O N
Input Source : CBL/SAT
Video Convert(IP Scaler) : ON, All sources
IP Scaler : "Analog & HDMI", All sources
Resolution : "AUTO", All sources
Setup Menu : ON
MAIN ZONE ON
ZONE2 OFF
・GUI display ⇒ HDMI output.
(
b
The input source can be switched to any source except CBL/SAT.)
