Denon AVR-S910W Service Manual

Magnify schematic / printed circuit
board diagrams - 2
(Pan & Zoom function)
ThePan&Zoomfunctionletsyouseewhichpartof
amagnieddiagramisbeingshowninaseparate
window.
[Example using Adobe Reader X]
On the "View" menu, point to "Zoom", and then click
"Pan & Zoom".
• The Pan & Zoom window appears on the screen.
[Example using Adobe Reader 9]
On the "Tools" menu, point to "Select & Zoom", and
then click "Pan & Zoom Window".
Magnify schematic / printed circuit
board diagrams - 3
(Loupe Tool function)
TheLoupeToolfunctionletsyoumagnifyaspecic
part of a diagram in a separate window.
[Example using Adobe Reader X]
On the "View" menu, point to "Zoom", and then click
"Loupe Tool".
• The Loupe Tool window appears on the screen.
[Example using Adobe Reader 9]
On the "Tools" menu, point to "Select & Zoom", and
then click "Loupe Tool Window".
5

Denon AVR-S910W Specifications

General

Receiver type	Surround
Audio output channels	7.2 channels
Power output per channel (1KHz@6 Ohm)	185 W
Power output per channel (20-20KHz@8 Ohm)	- W
HDMI in	8
Composite video in	2
Digital audio coaxial in	1
Wi-Fi	Yes
AM band range	520 - 1710 kHz
FM band range	87.5 - 107.9 MHz
Supported radio bands	AM, FM
Internet radio services supported	Pandora, SIRIUS Internet Radio, Spotify
Optical drive included	No
Display	-
Product color	Black
Audio decoders	Dolby Surround, Dolby TrueHD
AC input voltage	120 V
Power consumption (standby)	0.1 W
Power consumption (typical)	500 W
Audio formats supported	AAC, ALAC, FLAC, MP3, WAV, WMA

Weight and Dimensions

Depth	337.82 mm
Width	434.34 mm
Height	167.64 mm
Weight	9389 g
