Denon AVR-S910W Service Manual

The circuit around CY920 is faulty.
YES
YES
YES
YES
YES
Can the NET1.8V output voltage (1.8 V)
to U1071 (DC-DC Conv.) be conrmed?
Can the NET3.3V output voltage (3.3 V)
to Q1071 (FET-SW) be conrmed?
Can the NET1.2V output voltage (1.2 V)
to U1070 (DC-DC Conv.) be conrmed?
Can the NET2.5V output voltage (2.5 V)
to U1072 (DC-DC Conv.) be conrmed?
Are the versions of the Ethernet SBL and IMG displayed in Version
Check Mode?
Is E_POWER1 (U1018 uCOM 132 pin)
"Hi" ?
Is E_POWER3 (U1018 uCOM 134 pin)
"Hi" ?
Is E_POWER4 (U1018 uCOM 132 pin)
"Hi" ?
Is E_POWER2 (U1018 uCOM 133 pin)
"Hi" ?
The circuit of E_POWER1 between
U1018 and Q1071 are faulty.
The circuit of E_POWER3 between
U1018 and U1071 are faulty.
The circuit of E_POWER4 between
U1018 and U1070 are faulty.
The circuit of E_POWER2 between
U1018 and U1072 are faulty.
The circuit around U1071 (DC-DC.
Conv.) is faulty.
The circuit around Q1071 (FET-SW) is
faulty.
The circuit around U1070(DC-DC.
Conv.) is faulty.
The circuit around U1072 (DC-DC.
Conv.) is faulty.
The Ethernet software is faulty.
NO
NO
NO
NO
NO
NO
NO
NO
NO
YES
YES
YES
YES
91

Denon AVR-S910W Specifications

General

Receiver type	Surround
Audio output channels	7.2 channels
Power output per channel (1KHz@6 Ohm)	185 W
Power output per channel (20-20KHz@8 Ohm)	- W
HDMI in	8
Composite video in	2
Digital audio coaxial in	1
Wi-Fi	Yes
AM band range	520 - 1710 kHz
FM band range	87.5 - 107.9 MHz
Supported radio bands	AM, FM
Internet radio services supported	Pandora, SIRIUS Internet Radio, Spotify
Optical drive included	No
Display	-
Product color	Black
Audio decoders	Dolby Surround, Dolby TrueHD
AC input voltage	120 V
Power consumption (standby)	0.1 W
Power consumption (typical)	500 W
Audio formats supported	AAC, ALAC, FLAC, MP3, WAV, WMA

Weight and Dimensions

Depth	337.82 mm
Width	434.34 mm
Height	167.64 mm
Weight	9389 g
