Denon AVR-X3000 - Page 106

PCM5100
D/A
+20dB
+10dB
0dB
-20dB
-30dB
-40dB
-10dB
+20dB
+10dB
0dB
-20dB
-30dB
-40dB
-10dB
LINE IN
AVR-X3000
LEVEL DIAGRAM
ZONE2
200mVrms
+30dB
SP OUT
4.48Vrms/8Ω
+29dB
MAX. SIGNAL LEVEL
-20dBFS(DIG.IN)
LINE IN
＋
SPEAKER
R2A15218FP
GAIN
2.0Vrms=0dBFS
-10dBFS
-20dBFS
-30dBFS
-40dBFS
PCM5100
-2dB
R2A15218FP MAX. OUTPUT 3.8Vrms
PRE OUT
PRE OUT
159mVrms
To MAIN
TONE
NJW1194
MONO
HPF
MONO
from D/A
from F-ch
MUTE
106
