Denon AVR-X3000 Service Manual

1. µcom/DSP Version display mode
1.1. Operation specications
µcom/DSP version display mode:
When the set is started up in this mode, the version information is displayed.
Starting up:
Press the "Power operation (
X
)" button to turn on the power while pressing the "STATUS" and "DIMMER" buttons.
Now, press the "STATUS" button to the display the 2nd item information on the FL Display.
b
When the version is displayed on the FL Display, the version list is also displayed on the GUI.
1.2. Display Order
Error information(Refer to 1.3. Error display) →
q
Model destination information →
w
Serial Number
→
e
Firmware Package Version →
r
Main µ-com →
t
Main 1st Boot Loader →
y
Sub µ-com
→
u
Sub 1st Boot Loader→
i
DSP ROM →
o
Audio PLD →
Q0
GUI SFLASH
→
Q1
Ethernet(DM860A) 1st Boot Loader, Hardware ID →
Q2
Ethernet(DM860A) 2nd Boot Loader
→
Q3
Ethernet(DM860A) IMAGE →
Q4
Ethernet(DM860A)MAC ADDRESS information
q
Model destination information :
Model FLD
AVR-X3000 E3 model
A V R - X 3 0 0 0 E 3
AVR-X3000 E2 model
A V R - X 3 0 0 0 E 2
AVR-X3000 E1C model
A V R - X 3 0 0 0 E 1 C
w
Serial Number :
FLD
S / N . * * * * * * * * * *
e
Firmware Package Version :
FLD
P a c k a g e : * * * *
r
Main µ-com :
FLD
M a i n : * * * * * * * *
t
Main 1st Boot Loader :
FLD
M a i n F B L : * * . * *
y
Sub µ-com :
FLD
S u b : * * * * * * * *
u
Sub 1st Boot Loader :
FLD
S u b F B L : * * . * *
i
DSP ROM :
FLD
D S P : * * . * *
o
Audio PLD :
FLD
A u d i o P L D : * * . * *
19

Denon AVR-X3000 Specifications

General

Receiver type	Surround
Frequency range	10 - 100000 Hz
Output impedance	16 Ω
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	7.1 channels
Signal-to-Noise Ratio (SNR)	102 dB
Total Harmonic Distortion (THD)	0.08 %
Power output per channel (1KHz@6 Ohm)	135 W
Power output per channel (20-20KHz@8 Ohm)	105 W
HDMI in	7
Audio (L/R) in	5
Composite video in	3
Ethernet LAN (RJ-45) ports	1
Component video (YPbPr/YCbCr) in	2
Connectivity technology	Wired
Speakers connectivity type	Banana connector
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Image formats supported	JPG
Wi-Fi	No
RDS features	PTY, TP
AM band range	520 - 1710 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Internet radio services supported	Spotify, vTuner
Supported video modes	1080i, 1080p, 480p, 576p, 720p
Display	VFL
Color depth	24 bit
Aspect ratio	4:3, 16:9
Product color	Black
Audio decoders	DTS Neo:X, Dolby Digital, Dolby Digital EX, Dolby Digital Plus, Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD, DTS, DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), DTS-HD, DTS-HD Master Audio
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Apple docking compatibility	iPhone, iPod
AC input voltage	230 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	600 W
Cables included	AC

Weight and Dimensions

Depth	379 mm
Width	434 mm
Height	167 mm
Weight	10700 g
