Denon AVR-X3000 Service Manual

154
Pin Pin Name Symbol I/O
Pull up/
down
LvCnv STBY STOP
CEC
STBY
Function
89
P71/CS4#-C/
CS5#-C/CS6#-C/
CS7#-C
DIR CLK O - - L L L DIR control pin (LC89058W-E)
90
P70/CS3#-B/
ADTRG2#
DIR RST O - - L L L DIR RESET pin (LC89058W-E)
91 VCC VCC - - - - - - +3.3V
92
PB0/A8/PO24/
TIOCA9
CEC SEL O - - L L L CEC output LINE switching
93 VSS VSS - - - - - - GND
94
PA7/A7/PO23/
TIOCA8/TIOCB8/
TCLKH
NC O/O -/- - L L L Unused
95
PA6/A6/PO22/
TIOCA8
VSEL A I - - I I I
Master Volume rotation detection
pin(Rotary encoder)
96
PA5/A5/PO21/
TIOCA7/TIOCB7/
TCLKG
VSEL B I - - I I I
Master Volume rotation detection
pin(Rotary encoder)
97
PA4/A4/PO20/
TIOCA7
E POWER 2
(Reserve)
O -/- - L L L Unused
98
PA3/A3/PO19/
TIOCC6/TIOCD6/
TCLKF
DAC(ETHER)
MUTE
O - - L L L
DAC (ETHER) MUTE control pin
(PCM5100 for DM860)
99
PA2/A2/PO18/
TIOCC6/TCLKE
PRE Z2 MUTE O
- - L L L Z2 PRE OUT MUTE control pin
100
PA1/A1/PO17/
TIOCA6/TIOCB6
NC O - - L L L Unused
101
PA0/A0/BC0#/PO16/
TIOCA6
PRE MUTE O - - L L L
Sub Woofer PRE OUT MUTE control
pin
102 PE7/IRQ7-A/D15 ADV8003 INT2 I - - I I I
HDMI TX1.0SD INT2 input pin (ADV8003)
103 PE6/IRQ6-A/D14 ADV7850 INT1 I - - I I I HDMI RX INT1 input pin (ADV7850)
104 PE5/IRQ5-A/D13 ADV7850 INT2 I - - L L L HDMI RX INT2 input pin (ADV7850)
105 PE4/D12 ISEL A I/O - - I/L I/L I/L
Input Selector rotation detection
pin(Rotary encoder)
106 PE3/D11 ISEL B I/O - - I/L I/L I/L
Input Selector rotation detection
pin(Rotary encoder)
107 PE2/D10 VOL CLK O - - L L L
FUNCTION / VOLUME control pin
(R2A15218)
108 PE1/D9 VOL DATA O - - L L L
FUNCTION / VOLUME control pin
(R2A15218)
109 PE0/D8 PLD WRITE O - - L L L A.PLD /JTAG switching control pin
110 PD7/D7 JTAG TDO I - - L L L A.PLD rewriting control pin (JTAG)
111 PD6/D6
JTAG TMS/APLD
CS
O/O - - L L L A.PLD rewriting & control pin
112 PD5/D5
JTAG TDI/APLD
DATA/DAC DATA
O/O - - L L L
A.PLD rewriting & control /DAC control
pin
113 PD4/D4
JTAG TCK/APLD
CLK/DAC CLK
O/O - - L L L
A.PLD rewriting & control /DAC control
pin
114 P64/CS4#-B ADC RST O - - L L L A/D converter control pin (AK5358B)
115 P63/CS3#-A/CS7#-A NC O - - L L L Unused
116 P62/CS2#-A/CS6#-A E SPI CS O N3VPu - L L L
ETHERNET communication control
pin(DM860)
117
P61/CS1#/CS2#-B/
CS5#-A/CS6#-B/
CS7#-B
DAC MS O - - L L L D/A converter control pin (AK4358VQ)
118
P60/CS0#/CS4#-A/
CS5#-B
DAC RST O - - L L L D/A converter control pin (AK4358VQ)
119 PD3/D3 NC O - - L L L Unused
120 PD2/D2 NC O - - L L L Unused
121 PD1/D1 FL CLK O - - L L L VFD control pin
122 PD0/D0 FL DATA O - - L L L VFD control pin
123 P97/AN15 DA POWER O - - L L L
DIGITAL AUDIO POWER SUPPLY
(DA3.3V & DA1.2V) control pin.(ON:H)
124 P96/AN14 CEC POWER O -
- L L H
HDMI CEC POWER SUPPLY (CEC5V
& CEC3.3V & CEC1.8V) control pin.
(ON:H)
125 P95/AN13 DV POWER1 O - - L L
b
Digital VIDEO POWER SUPPLY
(DV5V & DV3.3V) control pin. *CEC
STANDBY : MODE1=H , MODE2=L ,
MODE3=L

Denon AVR-X3000 Specifications

General

Receiver type	Surround
Frequency range	10 - 100000 Hz
Output impedance	16 Ω
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	7.1 channels
Signal-to-Noise Ratio (SNR)	102 dB
Total Harmonic Distortion (THD)	0.08 %
Power output per channel (1KHz@6 Ohm)	135 W
Power output per channel (20-20KHz@8 Ohm)	105 W
HDMI in	7
Audio (L/R) in	5
Composite video in	3
Ethernet LAN (RJ-45) ports	1
Component video (YPbPr/YCbCr) in	2
Connectivity technology	Wired
Speakers connectivity type	Banana connector
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Image formats supported	JPG
Wi-Fi	No
RDS features	PTY, TP
AM band range	520 - 1710 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Internet radio services supported	Spotify, vTuner
Supported video modes	1080i, 1080p, 480p, 576p, 720p
Display	VFL
Color depth	24 bit
Aspect ratio	4:3, 16:9
Product color	Black
Audio decoders	DTS Neo:X, Dolby Digital, Dolby Digital EX, Dolby Digital Plus, Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD, DTS, DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), DTS-HD, DTS-HD Master Audio
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Apple docking compatibility	iPhone, iPod
AC input voltage	230 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	600 W
Cables included	AC

Weight and Dimensions

Depth	379 mm
Width	434 mm
Height	167 mm
Weight	10700 g
