Denon AVR-X3000 Service Manual

1.3. Error display
See the following table for each "Error information" display and its explanation (status).
Display order is
q
,
w
,
e
,
r
,
t
,
y
,
u
Condition Status FL Display Trouble shooting
q
Firm Check
NG
Compared with the destination setting on the
board. This is displayed when the model name
or destination information written into the
rmware does not match. (
b
)
F I R M E R R O R
• Please check the
destination-resistors
(
R2060/R2061,
DIGITAL B'D).
• Please write the
rmware of correct
destination.
w
SUB NG
No response from SUB microcomputer.
S U B E R R O R 0 1
• Please check SUB
(IC231) and arroud
circuits.
e
IP SCALER
NG
An error occurred in testing writing data
between IP SCALER and DDR.
I P S C A L E R E R R 0 1
• Please check IP
SCALER (IC151,
DIGITAL PCB) and
around circuits.
Testing writing data between IP SCALER and
DRR resulted in no response.
I P S C A L E R E R R 0 2
r
GUI Version
NG
Error occurs in GUI version and Main μ-com
version.(
b
)
G U I V E R . E R R O R
• Please check the
rmware of correct
version.
t
DIR NG
No response from DIR
D I R E R R O R 0 1
• Please check DIR
（
IC403, DIGITAL B'D)
and around circuits.
y
DSP NG
When DSP code boot is performed, the DSP
FLAG0 port does not change to "H" even if
DSP reset is executed.
D S P 1 E R R O R 0 1
• Please check DSP
（
IC408, DIGITAL B'D)
and around circuits.
Before DSP command is issued, the DSP
BUSY port does not change to "L".
D S P 1 E R R O R 0 2
When DSP data read is performed, executing
WRITE="L" does not result in ACK="H".
D S P 1 E R R O R 0 3
When DSP data read is performed, executing
REQ="L" does not result in ACK="L".
D S P 1 E R R O R 0 4
When DSP data writing is performed,
executing WRITE="H" does not result in
ACK="H".
D S P 1 E R R O R 0 5
When DSP data writing is performed,
executing REQ="L" does not result in
ACK="L".
D S P 1 E R R O R 0 6
u
EEPROM
NG
Error occurs in EEPROM checksum.(*** is a
block address number.)
E 2 P R O M E R R * * *
Status FL Display
b
The written Firmware and product settings
(model name, brand name, destination) are
compared. If Firmware that is not designed
for this product is written, ▲ or ▼ is
displayed in the rst column, as shown on
the right.
–
M a i n : * * * * * * * *
–
S U B : * * . * *
–
D S P : * * . * *
–
A u d i o P L D : * * . * *
21

Denon AVR-X3000 Specifications

General

Receiver type	Surround
Frequency range	10 - 100000 Hz
Output impedance	16 Ω
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	7.1 channels
Signal-to-Noise Ratio (SNR)	102 dB
Total Harmonic Distortion (THD)	0.08 %
Power output per channel (1KHz@6 Ohm)	135 W
Power output per channel (20-20KHz@8 Ohm)	105 W
HDMI in	7
Audio (L/R) in	5
Composite video in	3
Ethernet LAN (RJ-45) ports	1
Component video (YPbPr/YCbCr) in	2
Connectivity technology	Wired
Speakers connectivity type	Banana connector
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Image formats supported	JPG
Wi-Fi	No
RDS features	PTY, TP
AM band range	520 - 1710 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Internet radio services supported	Spotify, vTuner
Supported video modes	1080i, 1080p, 480p, 576p, 720p
Display	VFL
Color depth	24 bit
Aspect ratio	4:3, 16:9
Product color	Black
Audio decoders	DTS Neo:X, Dolby Digital, Dolby Digital EX, Dolby Digital Plus, Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD, DTS, DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), DTS-HD, DTS-HD Master Audio
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Apple docking compatibility	iPhone, iPod
AC input voltage	230 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	600 W
Cables included	AC

Weight and Dimensions

Depth	379 mm
Width	434 mm
Height	167 mm
Weight	10700 g
