3.5.6 Audio system conrmation items
g. XX: Refer to the block diagram of the g.XXth.
Conrmation item FL display settings Contents of conrmationRemarks
A01
Analog (signal) Path
A 0 1 : A N A L O G P A S S
Input Source : CBL/SAT
Input Mode : ANALOG(xed)
Sound mode : DIRECT
Amp assign : Surround Back
ZONE2 : OFF
·Analog input
⇒
Speaker output (FRONT L,R)
·Analog input
⇒
Preout output (FRONT L,R) [except E3]
(
b
As the input source, you can switch from CBL/SAT to other ones.)
A02
Digital (signal) Path
(MAIN ZONE)
A 0 2 : D I G I T A L
Input Source : CBL/SAT
Input Mode : DIGITAL(xed)
Sound mode: MULTI CH STEREO
Amp assign : Surround Back
ZONE2 : OFF
·Digital input
⇒
Speaker output (Front L/R, Center, Surround L/R, Surround Back L/R)
· Digital input
⇒
Preout output (Front L/R, Center, Subwoofer1/2, Surround L/R, Surround Back
L/R) [except E3]
(
b
As the input source, you can switch from CBL/SAT to other ones.)
A03
Digital (signal) Path
(ZONE2)
A 0 3 : D I G I T A L - Z 2
Input Source : NETWORK
Input Mode : Auto
Sound mode: STEREO
Amp assign : ZONE2
ZONE2 : ON
ZONE2 Source : Source
·Digital(PCM) input
⇒
Speaker output (Surround Back L/R)
·Digital(PCM) input
⇒
Preout output (ZONE2 L/R)
(
b
As the input source, you can switch from NETWORK to other ones.)
A05
HDMI (signal) Path
A 0 5 : H D M I
Input Source : CBL/SAT
Input Mode : HDMI(xed)
Sound mode: STEREO
Amp assign : Surround Back
ZONE2 : OFF
·HDMI Input
⇒
Speaker output (Front L/R)
·HDMI Input
⇒
Preout output (Front L/R) [except E3]
(
b
As the input source, you can switch from CBL/SAT to other ones.)
A06
A/D (signal) Path
(MAIN ZONE)
A 0 6 : A D
Input Source : CBL/SAT
Input Mode : Analog(xed)
Sound mode: MULTI CH STEREO
Amp assign : Surround Back
ZONE2 : OFF
·Analog input
⇒
Speaker output (Front L/R, Center, Surround L/R, Surround Back L/R)
· Analog input
⇒
Preout output (Subwoofer1/2) [E3]
· Analog input
⇒
Preout output (Front L/R, Center, Subwoofer1/2, Surround L/R, Surround Back
L/R) [except E3]
(
b
As the input source, you can switch from CBL/SAT to other ones.)
A07
Amp Assign (signal) Path
(Amp Assign : ZONE2)
A 0 7 : A S S I G N - Z 2
Input Source : CBL/SAT
Input Mode : Auto
Sound mode : STEREO
Amp assign : ZONE2
ZONE2 : ON
ZONE2 Source : Source
·Analog input
⇒
Speaker output (Surround Back L/R)
·Analog input
⇒
Preout output (ZONE2 L/R)
(
b
As the input source, you can switch from CBL/SAT to other ones.)
A11
Amp Assign (signal) Path
( Amp Assign :
5.1ch (Bi-Amp)
A 1 1 : A S S I G N - B i A M P
Input Source : CBL/SAT
Input Mode : Auto
Sound mode: MULTI CH STEREO
Amp assign : (Bi-Amp)
ZONE2 OFF
·Analog input
⇒
Speaker output (Surround Back L/R)
(
b
As the input source, you can switch from CBL/SAT to other ones.)
A14
Front Height (signal) Path
A 1 4 : F R O N T H E I G H T
Input Source : CBL/SAT
Input Mode : Auto
Sound mode: MULTI CH STEREO
Amp assign : Front Height
ZONE2 OFF
·Analog input
⇒
Speaker output (Surround Back L/R)
(
b
As the input source, you can switch from CBL/SAT to other ones.)
A15
Front Wide (signal) Path
A 1 5 : F R O N T W I D E
Input Source : CBL/SAT
Input Mode : Auto
Sound mode: MULTI CH STEREO
Amp assign : Front Wide
ZONE2 OFF
·Analog input
⇒
Speaker output (Surround Back L/R)
(
b
As the input source, you can switch from CBL/SAT to other ones.)
g.08
g.09
g.10
g.11
g.12
g.13
g.14
g.15
g.16
