Denon AVR-X3000 Service Manual

VIDEO B'D aw.
B
Extend DIGITAL B'D using a jig.
Check power supply voltage and control signal of
video selector IC (IC511 , IC516).
(VIDEO B'D)
V +5V : J5019
V +5V : J5040
V select : J5007 = H (3.3V)
J5012 = H (3.3V)
J5016 = H (3.3V)
COMPONENT select : J5023 = H (3.3V)
J5021 = L (0V)
Defective connection of SIDE CNT B'D (BN28B).
Video selector IC (IC511 or IC516 ) aw.
Defective the parts between video selector IC(IC511 ,
IC516 ) .
Defective the soldering video selector IC(IC511 , IC516 )
or video selector IC (IC511 or IC516 ) aw.
Check the signal input to video selector
IC (IC511 , IC516).
V : J5001
OMPONENT-Y : J5006
COMPONENT-Cb : J5004
COMPONENT-Cr : C5160
(VIDEO B'D)
Check the signal output from video selector
IC (IC511 , IC516).
(VIDEO B'D) to DIGITAL B'D
V : BN21B-17pin
OMPONENT-Y : BN21B-15pin
COMPONENT-Cb : BN21B-13pin
COMPONENT-Cr : BN21B-11pin
MONITOR OUT
Defective connection of FRONT CNT B'D (BN21B) or
FRONT CNT B'D pattern aw
NO
NO
NO
YES
YES
YES
87

Denon AVR-X3000 Specifications

General

Receiver type	Surround
Frequency range	10 - 100000 Hz
Output impedance	16 Ω
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	7.1 channels
Signal-to-Noise Ratio (SNR)	102 dB
Total Harmonic Distortion (THD)	0.08 %
Power output per channel (1KHz@6 Ohm)	135 W
Power output per channel (20-20KHz@8 Ohm)	105 W
HDMI in	7
Audio (L/R) in	5
Composite video in	3
Ethernet LAN (RJ-45) ports	1
Component video (YPbPr/YCbCr) in	2
Connectivity technology	Wired
Speakers connectivity type	Banana connector
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Image formats supported	JPG
Wi-Fi	No
RDS features	PTY, TP
AM band range	520 - 1710 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Internet radio services supported	Spotify, vTuner
Supported video modes	1080i, 1080p, 480p, 576p, 720p
Display	VFL
Color depth	24 bit
Aspect ratio	4:3, 16:9
Product color	Black
Audio decoders	DTS Neo:X, Dolby Digital, Dolby Digital EX, Dolby Digital Plus, Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD, DTS, DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), DTS-HD, DTS-HD Master Audio
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Apple docking compatibility	iPhone, iPod
AC input voltage	230 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	600 W
Cables included	AC

Weight and Dimensions

Depth	379 mm
Width	434 mm
Height	167 mm
Weight	10700 g
