Denon AVR-X3000 Service Manual

BK903
CMD1A 629
OPTION
OPTION
OPTION
D
S
C X
V
OPTION
AC220~240V : 100uF/400V
AC100~120V : 100uF/200V
ZD901
39V
ZD902
39V
ZD903
22V
ZD904
JUM PER
ZD905
JUM PER
ZD906
JUM PER
ZD907
JUM PER
R9004
470K(0.2 W)
C9006
0.1uF(1608)
C9007
0.1uF(1608)
C9008
0.1uF(1608)
C9010
0.1uF(1608)
R9005
47(1608)
Q9001
KTC 3198Y
R9006
1M(1608)
Q9002
KTC 3198Y
R9002
1M(0 .2W)
R9003
1M(0 .2W)
D9006
1N4007
D9005
1N4007
LF902
LF-4ZB -E273H
D9001
1N4007
D9002
1N4007
D9003
1N4007
D9004
1N4007
CX902
OPEN
C9004
100uF/400V(N HA)
R9007
270K(1608)
R9015
15K(1608)
R9016
1K(1608)
R9014
270K(1608)
R9010
1M(0 .2W)
R9008
2.2M(0 .2W)
ZD908
39V
ZD909
39V
ZD910
39V
R9009
2.2M(0 .2W
)
ZD917
22
V
ZD916
22V
ZD915
22V
ZD914
22V
ZD913
22V
ZD912
22V
ZD911
22V
C9012
1000P/1K V
R9017
6.8(0.2W )
C9017
47/25V(NXA )
R9013
10(1608)
D9013 AP01C
12
3 4
IC902
PC123Y22
ZD920
39V
C9016
0.1uF(1608)
D9008
1N4007
ZD918
22V
C9009
10/50V(NXA )
D9009
1N4007
C9018
0.1uF(1608)
C9019
4.7uF(1608)
C9020
5600uF/6.3V (NXA)
C9021
5600uF/6.3V (NXA)
C9022
5600uF/6.3V (NXA)
C9023
OPEN
C9028
2200P 250V
C9029
0.1uF(1608)
R9019
3.3K(0 .2W)
R9018
56(0.2W)
C9002
0.01uF 250V
C9003
0.01uF 250V
R9030
OPEN( 1608)
C9030
OPEN( 1608)
1
2
3
4
5
6
7
8
10
11
T9001
ST-4430A
9 10876
5 3 2 1
IC901 T OP258MG
1
2
3
D9014
OPEN
1
3
2
D9012
SRL3060P
After primary side rectification
(Caution: High voltage, electric shock)
Primary drain
(Caution: High voltage, electric shock)
After secondary rectifications
A
B
C
Operation waveform for each part
A B C
A B C
SMPS unit
(Unloaded)
Set
98

Denon AVR-X3000 Specifications

General

Receiver type	Surround
Frequency range	10 - 100000 Hz
Output impedance	16 Ω
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	7.1 channels
Signal-to-Noise Ratio (SNR)	102 dB
Total Harmonic Distortion (THD)	0.08 %
Power output per channel (1KHz@6 Ohm)	135 W
Power output per channel (20-20KHz@8 Ohm)	105 W
HDMI in	7
Audio (L/R) in	5
Composite video in	3
Ethernet LAN (RJ-45) ports	1
Component video (YPbPr/YCbCr) in	2
Connectivity technology	Wired
Speakers connectivity type	Banana connector
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Image formats supported	JPG
Wi-Fi	No
RDS features	PTY, TP
AM band range	520 - 1710 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Internet radio services supported	Spotify, vTuner
Supported video modes	1080i, 1080p, 480p, 576p, 720p
Display	VFL
Color depth	24 bit
Aspect ratio	4:3, 16:9
Product color	Black
Audio decoders	DTS Neo:X, Dolby Digital, Dolby Digital EX, Dolby Digital Plus, Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD, DTS, DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), DTS-HD, DTS-HD Master Audio
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Apple docking compatibility	iPhone, iPod
AC input voltage	230 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	600 W
Cables included	AC

Weight and Dimensions

Depth	379 mm
Width	434 mm
Height	167 mm
Weight	10700 g
