Denon AVR-X7200W Service Manual

YES
YES
YES
In the same way as for Network connection troubleshooting, check the
CY920 power supply and Ethernet SBL, and that the IMG version is displayed
correctly.
Is the Wi-Fi/BT antenna cable inserted correctly into CY920?
Is the Bluetooth device compatible with the A2DP prole?
Is the Bluetooth function enabled on the Bluetooth device?
Connect the Wi-Fi/BT antenna cable correctly.
Use a device that is A2DP prole compatible.
Enable the Bluetooth function and try connecting
again.
NO
NO
NO
5.2.2. Cannot connect to the Bluetooth (Case of AVR-X7200WA model)
Checking the unit
Check the Bluetooth
d
d
d
d
d
d
d
d
d
d
112

Denon AVR-X7200W Specifications

General

Receiver type	Surround
Input sensitivity	200 mV
Audio output channels	11.2 channels
Signal-to-Noise Ratio (SNR)	102 dB
Power output per channel (1KHz@6 Ohm)	190 W
Power output per channel (20-20KHz@8 Ohm)	210 W
HDMI in	8
Audio (L/R) in	7
Composite video in	5
Digital audio optical in	2
Ethernet LAN (RJ-45) ports	1
Component video (YPbPr/YCbCr) in	3
12V trigger	Yes
Speakers connectivity type	-
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Optical drive included	No
Display	LCD
Product color	Black
Audio decoders	Dolby TrueHD, DTS 96/24, DTS-ES, DTS-HD Master Audio
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	780 W

Weight and Dimensions

Depth	427 mm
Width	434 mm
Height	196 mm
Weight	17800 g
