Denon AVR-X7200W Service Manual

Check the USB device being used
Checking the unit (If no picture is output)
YES
YES
Is the USB device supported by this unit?
Check the VIDEO circuit.
Is a USB hub being used?
Are digital video signals (920PCK, 920VD0 - 920VD7) output from
CX870 or CY920 to U3200 (V.PLD)?
This unit supports devices in the FAT16 and FAT32-
formatted mass storage class, MTP-compatible devices
and iPods (with the exception of some models).
Do not use a USB hub.
NO
YES
NO
Checking the unit
Checking the unit:(If no sound is output)
YES
YES
YES
YES
Can a voltage (5V) be conrmed between pin 1 and pin 4 of N5559 (USB Connec-
tor) on USB PCB?
The USB signal circuit between CX870 or CY920 and N5559 of the
USB PCB are faulty.
Check the AUDIO circuit of U101 (DSP) or later.
Case of AVR-X7200W model
Are N5560 of the CX870MIDDLE PCB and N904 of the USB PCB correctly con-
nected?
Case of AVR-X7200WA model
Are N603 of the DIGITAL PCB and N904 of the USB PCB correctly connected?
Are I2S signal output to pin 26, 28, 30, 34 of the N906 DIGITAL PCB
?
(The 30, 32, 34pin in the case of DSD)
Are audio signal output to pin 85 of U1201 (A.PLD) on DIGITAL PCB.
Case of AVR-X7200W model
The circuit around U902 of the CX870MID-
DLE PCB is faulty.
Case of AVR-X7200WA model
The circuit around U603 of the DIGITAL
PCB is faulty.
Connect the connectors correctly.
NO
NO
5.3. A connected USB device is not recognized.
5.4. No picture or sound is output
The circuit around CX870 or CY920, U3200
(V.PLD) is faulty.
The circuit around CY920 or CX870 or CX870MID-
DLE PCB is faulty.
The circuit around U1201 (A.PLD) is faulty.
NO
NO
NO
d
d
d
d
d
d
113

Denon AVR-X7200W Specifications

General

Receiver type	Surround
Input sensitivity	200 mV
Audio output channels	11.2 channels
Signal-to-Noise Ratio (SNR)	102 dB
Power output per channel (1KHz@6 Ohm)	190 W
Power output per channel (20-20KHz@8 Ohm)	210 W
HDMI in	8
Audio (L/R) in	7
Composite video in	5
Digital audio optical in	2
Ethernet LAN (RJ-45) ports	1
Component video (YPbPr/YCbCr) in	3
12V trigger	Yes
Speakers connectivity type	-
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Optical drive included	No
Display	LCD
Product color	Black
Audio decoders	Dolby TrueHD, DTS 96/24, DTS-ES, DTS-HD Master Audio
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	780 W

Weight and Dimensions

Depth	427 mm
Width	434 mm
Height	196 mm
Weight	17800 g
