Denon AVR-X7200W Service Manual

Paths conrmation item Display Settings Contents of conrmation Remarks
6
A/D
(MAIN ZONE)
A 0 6 : A D
Input Source : CBL/SAT
Input Mode : Analog(xed)
Sound mode : Multi Ch Stereo
Vol. : 60.0（-20.0dB）
Amp assign : 9.1ch
Height Speakers=2 Height Speakers
Height Layout=Front Height
Speaker Select : Floor
Speaker Cong : All Speaker=Small/Subwoofer=2spkrs
ZONE2 : OFF
ZONE3 : OFF
・Analog input ⇒ Speaker output (Front L/R, Center, Surround L/R, Surround Back L/R, Front Wide L/R)
・ Analog input ⇒ Preout output, SW(20Hz) (Front L/R, Center, Subwoofer1/2, Surround L/R, Surround Back L/R, Front
Wide L/R)
(
b
The input source can be switched to any source except CBL/SAT.）
7
Amp Assign
(ZONE2)
A 0 7 : A S S I G N - Z 2
Input Source : CBL/SAT
Input Mode : Auto
Sound mode : Stereo
Amp assign : 7.1ch + ZONE2
Speaker for ZONE2 : Surround Back
ZONE2 : ON
Z2 Source : Source
Z2 Vol : 60（-20dB)
ZONE3 : OFF
・Analog input ⇒ Speaker output (Surround Back L/R → ZONE2 L/R)
・Analog input ⇒ Preout output (ZONE2 L/R)
(
b
The input source can be switched to any source except CBL/SAT.）
8
Amp Assign
(ZONE3)
A 0 8 : A S S I G N - Z 3
Input Source : CBL/SAT
Input Mode : Auto
Sound mode : Stereo
Amp assign : 7.1ch + ZONE3
Speaker for ZONE3 : FRONT WIDE/HEIGHT 2
ZONE2 : OFF
ZONE3 : ON
ZONE3 Source : Source
Z3 Vol. : 60.0（-20.0dB）
・Analog input ⇒ Speaker output (Front Wide/Height2 L/R → ZONE3 L/R)
・Analog input ⇒ Preout output (ZONE3 L/R)
(
b
The input source can be switched to any source except CBL/SAT.）
9
Amp Assign
（ZONE2/ZONE3-MONO）
A 0 9 : A S S I G N - Z 3 / 3 M
Input Source : CBL/SAT
Input Mode : Auto
Sound mode : STEREO
Amp assign : 7.1ch + ZONE2/3-MONO
Speaker for ZONE2/3 : HEIGHT1
ZONE2 : ON
Z2 Source : Source
Z2 Vol : 60（-20dB）
ZONE3 : ON
Z3 Source : Source
Z3 Vol : 60（-20dB）
・Analog input ⇒ Speaker output (Height1 L → ZONE2 MONO, Height2 R → ZONE3 MONO)
・Analog input ⇒ Preout output (ZONE2 L/R → ZONE2 MONO, ZONE3 L/R → ZONE3 MONO)
(
b
The input source can be switched to any source except CBL/SAT.）
10
Amp Assign
(7.1ch (Bi-Amp)
A 1 1 : A S S I G N - B i A M P
Input Source : CBL/SAT
Input Mode : Auto
Sound mode : Multi Ch Stereo
Vol. : 60.0（-20.0dB）
Amp assign : 7.1ch (Bi-Amp)
Speaker for Bi-Amp : SURROUND BACK
ZONE2 : OFF
ZONE3 : OFF
・Analog input ⇒ Speaker output (Surround Back L/R → Front L/R）
(
b
The input source can be switched to any source except CBL/SAT.）
11
Front Height
A 1 4 : F R O N T H E I G H T
Input Source : CBL/SAT
Input Mode : Auto
Sound mode : Multi Ch Stereo
Vol. : 60.0（-20.0dB）
Amp assign : 11.1ch
Height Speakers : 4Height Speakers
Height Layout : Top Front & Top Rear
Pre-out Channel : Top Rear
Speaker Cong : Front Wide=None
Speaker Select : Floor & Height
ZONE2 : OFF
ZONE3 : OFF
・Analog input ⇒ Speaker output (Height 1 L/R → Top Front L/R）
・Analog input ⇒ Preout output (Height 1 L/R → Top Front, Height 2 L/R → Top Rear)
(
b
The input source can be switched to any source except CBL/SAT.）
12
Front Wide
A 1 5 : F R O N T W I D E
Input Source : CBL/SAT
Input Mode : Auto
Sound mode : Multi Ch Stereo
Vol. : 60.0（-20.0dB）
Amp assign : 11.1ch
Height Speakers : 4 Height Speakers
Height Layout : Front Height & Top Middle
Wide/Height2 : Front Wide
Speaker Cong: S.Back=None
Speaker Select : Floor
ZONE2 : OFF
ZONE3 : OFF
・Analog input ⇒ Speaker output (Front Wide L/R）
・Analog input ⇒ Preout output (Front Wide L/R）
(
b
The input source can be switched to any source except CBL/SAT.）
g.06a
g.06b
g.07
g.08
g.09
g.10a
g.10b
g.11a
g.11b
g.12a
g.12b
28

Denon AVR-X7200W Specifications

General

Receiver type	Surround
Input sensitivity	200 mV
Audio output channels	11.2 channels
Signal-to-Noise Ratio (SNR)	102 dB
Power output per channel (1KHz@6 Ohm)	190 W
Power output per channel (20-20KHz@8 Ohm)	210 W
HDMI in	8
Audio (L/R) in	7
Composite video in	5
Digital audio optical in	2
Ethernet LAN (RJ-45) ports	1
Component video (YPbPr/YCbCr) in	3
12V trigger	Yes
Speakers connectivity type	-
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Optical drive included	No
Display	LCD
Product color	Black
Audio decoders	Dolby TrueHD, DTS 96/24, DTS-ES, DTS-HD Master Audio
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	780 W

Weight and Dimensions

Depth	427 mm
Width	434 mm
Height	196 mm
Weight	17800 g
