Denon AVR-X7200W Service Manual

Paths conrmation item Display Settings Contents of conrmation Remarks
13
7.1CH IN
A 1 9 : 7 . 1 C H I N
Input Source : CBL/SAT
Input Mode : 7.1CH IN
Vol. : 60.0（-20.0dB）
Amp assign : 9.1ch
ZONE2 : OFF
ZONE3 : OFF
・7.1CH IN input ⇒ Speaker output (Front L/R, Center, Surround L/R, S.Back L/R)
・7.1CH IN input ⇒ Preout output (Front L/R, Center, Surround L/R, S. Back L/R, Subwoofer)
(
b
The input source can be switched to any source except CBL/SAT.）
14
Front Amp>>Height 1
A 2 0 : F - A M P H E I G H T
Input Source : CBL/SAT
Input Mode : Auto
Sound mode: Multi ch Stereo
Vol. : 60.0（-20.0dB）
Amp assign : 11.1ch
Height Speakers : 4Height Speakers
Height Layout : Top Front & Top Rear
Pre-out Channel : Front & Top Rear
Speaker Conog : Surround Back=None
Speaker Select : Floor & Height
ZONE2 : OFF
ZONE3 : OFF
・Analog input ⇒ Speaker output (Height1 L/R → Top Front L/R）
・Analog input ⇒ Preout output (Height1 L/R → Top Front, Height2 → Top Rear L/R）
(
b
The input source can be switched to any source except CBL/SAT.）
15
Front Amp>>Front Wide
A 2 1 : F - A M P W I D E
Input Source : CBL/SAT
Input Mode : Auto
Sound mode : Multi ch Stereo
Vol. : 60.0（-20.0dB）
Amp assign : 11.1ch
Height Speakers : 2Height Speakers
Height Layout : Front Height
Pre-out Channel : Front
Speaker Select : Front
ZONE2 : OFF
ZONE3 : OFF
・Analog input ⇒ Speaker output (Front Wide L/R)
(
b
The input source can be switched to any source except CBL/SAT.）
16
Wide/Height Amp>>Surround Back
A 2 3 : H - A M P B A C K
Input Source : CBL/SAT
Input Mode : Auto
Sound mode : Multi ch Stereo
Vol. : 60.0（-20.0dB）
Amp assign : 7.1ch+ZONE2
Speakers for ZONE2 : FRONT WIDE/HEIGHT 2
Height Layout : Front Height
Speaker Select : Floor
ZONE2 : OFF
ZONE3 : OFF
・Analog input ⇒ Speaker output (Surround Back L/R)
(
b
The input source can be switched to any source except CBL/SAT.）
g.13
g.14a
g.14b
g.15a
g.15b
g.16a
g.16b
29

Denon AVR-X7200W Specifications

General

Receiver type	Surround
Input sensitivity	200 mV
Audio output channels	11.2 channels
Signal-to-Noise Ratio (SNR)	102 dB
Power output per channel (1KHz@6 Ohm)	190 W
Power output per channel (20-20KHz@8 Ohm)	210 W
HDMI in	8
Audio (L/R) in	7
Composite video in	5
Digital audio optical in	2
Ethernet LAN (RJ-45) ports	1
Component video (YPbPr/YCbCr) in	3
12V trigger	Yes
Speakers connectivity type	-
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Optical drive included	No
Display	LCD
Product color	Black
Audio decoders	Dolby TrueHD, DTS 96/24, DTS-ES, DTS-HD Master Audio
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	780 W

Weight and Dimensions

Depth	427 mm
Width	434 mm
Height	196 mm
Weight	17800 g
