Denon AVR-X7200W User Manual

TV Format
Set the video signal format to be output for the TV you are using.
o
Format
NTSC
(Default):
Select NTSC output.
PAL: Select PAL output.
“Format” can also be set by the following procedure. However, the menu screen
is not displayed. Following the display content to make the setting.
1.
Press and hold the main unit’s o and p at the same time for at least 3
seconds.
“
z
Video Format <NTSC>” appears on the display.
2.
Use the main unit’s o or p and set the video signal format.
3. Press the main unit’s ENTER to complete the setting.
NOTE
When a format other than the video format of the connected TV is set, the picture
will not be displayed properly.
Contents Connections Playback Settings Tips Appendix
218
Front panel Display Rear panel Remote Index

Denon AVR-X7200W Specifications

General

Receiver type	Surround
Input sensitivity	200 mV
Audio output channels	11.2 channels
Signal-to-Noise Ratio (SNR)	102 dB
Power output per channel (1KHz@6 Ohm)	190 W
Power output per channel (20-20KHz@8 Ohm)	210 W
HDMI in	8
Audio (L/R) in	7
Composite video in	5
Digital audio optical in	2
Ethernet LAN (RJ-45) ports	1
Component video (YPbPr/YCbCr) in	3
12V trigger	Yes
Speakers connectivity type	-
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Optical drive included	No
Display	LCD
Product color	Black
Audio decoders	Dolby TrueHD, DTS 96/24, DTS-ES, DTS-HD Master Audio
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	780 W

Weight and Dimensions

Depth	427 mm
Width	434 mm
Height	196 mm
Weight	17800 g
