11
D-A03
Double-speed mode
Press the MD-REC button in the stop mode to switch to the double/constant-speed mode cyclically.
During the double-speed mode,
lights up.
N
H
TNO Display
N:NORMAL SPEED
H:HIGH SPEED
STEP NO Display
Time Display
TNO Display
STEP NO Display
Time Display
Coefficient name Coefficient
Readout of coefficient
2.Time display: Blank from the stop
mode to STEP 4
Lights when double-speed mode
1.STEP NO. : 0 when stopped
CD TEST
2. MD test mode (Refer to page 12 and after.)
Button used during MD test mode
Button Name Function
CD-PLAY To feed the menu of the TEST mode (1) (to feed the menu relating to adjustment and EEPROM)
TUNER To feed the menu of the TEST mode (2) (to feed the menu mainly relating to continuous
playback and recording)
AUX To feed the menu of the TEST mode (3) (to feed the menu of INNER and JUMP SELECT, etc.)
MD REC To feed the menu of the TEST mode in reverse (to feed the menu in each test mode in reverse)
MD-PLAY To select, determine and start the menu
MD-STOP To stop each test item and to select the next upper menu.
(M-) SKIP-UP ( ) 1. Forced slide feeding (FWD) 2. JUMP operation 3. Address setting value up, etc.
(M-) SKIP-DOWN ( ) 1. Forced slide feeding (REV) 2. JUMP operation 3. Address setting value down, etc.
VOL-UP Set value UP
VOL-DOWN Set value DOWN
CD-STOP 1. To switch laser by EJECT 2. To switch display during continuous playback, etc.
POWER To operation mode without automatic adjustment
MD-EJECT Normal EJECT operation
