D-A03
DISASSEMBLY
(Follow the procedure below in reverse order when reassembling)
1. Rear Cover & Front Panel
1) Remove 14 rear screws
1
and 4 (E3: 2) bottom screws
2
on the Rear Cover.
2) Disconnect connectors and wire
3
~
7
on the Front Panel.
The Rear Cover and Front Panel can be detached
respectively.
2. Main P.W.B.
1) Remove 5 screws
8
.
2) Disconnect 2 FFCs, 10 connectors on the Main P.W.B.
2
8
4
5P Connector
3
4P Connector
5
6P Connector
7
1P Earth Lug
6
11P Connector
Connectors
Main P.W.B.
Connectors
FFC
FFC
10P Connector
3P Connector
1
1
1
8
