Denon D-A03 User Manual

39
D-A03
39 XOUT X_OUT O Osc. output 8.38MHz 
40 Vss Vss GND GND 4.6
41 P27 Surround O Surround ON/OFF, H: ON 0
42 P26 /CD_PU_IN I CD PU inner most detect, L: Inner most 5.0
43 P25 /DR_OP_IN I CD DOOR open switch detect, L: OPEN 5.0
44 P24 /DR_CL_IN I CD DOOR close switch detect, L: CLOSE 0
45 P23/DIG19 /SYS_MUTE O Pre-amp MUTE, L: ON 4.96
46 P22/DIG18 /CD_RESET O CD RESET output, H: When other than CD 0
47 P21/DIG17 SP_MUTE O Power amp MUTE, L: ON 4.96
48 P20/DIG16 DR_M- O Door MOTOR control, at CLOSE H PULSE 
49 P17/DIG15 DR_M+ O Door MOTOR control, at OPEN H PULSE 
50 P16/DIG14 /CD_FUNC O CD power control, H: Other than CD 0
51 P15/DIG13 SDB O SDB switching, 81pin operate at H, H: ON 0
52 P14/DIG12 P14 O L: Output fixed 0
53 P13/DIG11 P13 O L: Output fixed 0
54 P12/DIG10 P12 O L: Output fixed 0
55 P11/DIG9 P11 O L: Output fixed 0
56 P10/DIG8 P10 O L: Output fixed 0
57 P07/DIG7 P07 O L: Output fixed 0
58 P06/DIG6 P06 O L: Output fixed 0
59 P05/DIG5 P05 O L: Output fixed 0
60 P04/SEG36/DIG4 P04 O L: Output fixed 0
61 P03/SEG35/DIG3 P03 O L: Output fixed 0
62 P02/SEG34/DIG2 P02 O L: Output fixed 0
63 P01/SEG33/DIG1 P01 O L: Output fixed 0
64 P00/SEG32/DIG0 P00 O L: Output fixed 0
65 P37/SEG31 P37 O L: Output fixed 0
66 P36/SEG30 P36 O L: Output fixed 0
67 P35/SEG29 P35 O L: Output fixed 0
68 P34/SEG28 P34 O L: Output fixed 0
69 P33/SEG27 P33 O L: Output fixed 0
70 P32/SEG26 P32 O L: Output fixed 0
71 P31/SEG25 P31 O L: Output fixed 0
72 P30/SEG24 P30 O L: Output fixed 0
73 P97/SEG23 P97 O L: Output fixed 0
74 P96/SEG22 P96 O L: Output fixed 0
75 P95/SEG21 P95 O L: Output fixed 0
76 P94/SEG20 P94 O L: Output fixed 0
77 P93/SEG19 P93 O L: Output fixed 0
78 P92/SEG18 P92 O L: Output fixed 0
79 P91/SEG17 P91 O L: Output fixed 0
80 P90/SEG16 P91 O L: Output fixed 0
81 P87/SEG15 SDB I SDB switching, L: 75342M use, H: 51pin L/H 0
82 P86/SEG14 P86 O L: Output fixed 0
83 P85/SEG13 P85 O L: Output fixed 0
84 P84/SEG12 P84 O L: Output fixed 0
85 P83/SEG11 P83 O L: Output fixed 0
86 P82/SEG10 P82 O L: Output fixed 0
87 P81/SEG09 P81 O L: Output fixed 0
88 P80/SEG08 P80 O L: Output fixed 0
89 PA7/SEG07 PA7 O L: Output fixed 0
90 PA6/SEG06 PA6 O L: Output fixed 0
91 VCC VCC I +5v 5
92 PA5/SEG05 PWB_test I H: PWB check MODE, L: Normal 0
93 PA4/SEG04 PA4 O L: Output fixed 0
94 PA3/SEG03 PA3 O L: Output fixed 0
95 PA2/SEG02 PA2 O L: Output fixed 0
96 PA1/SEG01 LCD_RESET O LC35811W reset output, L: reset 5
97 PA0/SEG00 Door cont I Door control switch, H: Fixed 5
98 VEE VEE I GND 0
99 AVss AVSS I GND 0
100 VREF Vref I +5V 5
Function
I/O
Pin
No.
Pin Name
Symbol
Voltage
(V)
