61
D-A03
PARTS LIST OF MD MECHANISM (For Hong Kong model)
Ref. No. Part No. Part Name Remarks
Q'ty
2 937 0246 207 Drive Chassis (A) 1
3 937 0246 304 Drive Chassis (B) 1
4 937 0279 300 Cartridge Holder Ass’y 1
5 937 0247 400 Slider Lever Ass’y 1
7 937 0247 002 Arm,Holder 1
8 937 0247 109 Plate,Switch 1
9 937 0279 407 Arm,Head Up Shift 1
10 937 0247 303 Lever,Cam Plate 1
12 937 0247 604 Spring,Loading 1
14 937 0247 701 Spring,Grip 1
15 937 0247 808 Spring,Shaft 1
16 937 0247 905 Spring,Loading Arm 1
17 937 0248 001 Spring,Shaft Arm 1
18 937 0248 205 Gear,Loading (A) 1
19 937 0248 302 Gear,Middle (A) 1
20 937 0248 409 Gear,Middle (B) 1
21 937 0248 506 Gear,Middle (C) 1
22 937 0248 603 Gear,Middle (D) 1
24 937 0248 700 Rack,Grip 1
27 937 0248 807 Drive Shaft Ass’y 1
28 937 0248 904 Shaft,Pickup Slide 1
30 937 0249 107 Cover,Shield,Top 1
31 937 0249 301 Cover,Shield,Side 1
32 937 0249 204 Cover,Shield,Bottom 1
33 937 0249 408 Cushion,Shield Cover 4
34 937 0259 605 Magnetic Head 1
35 937 0260 102 MD Pickup Unit Ass’y 1
36 937 0248 108 Spring,Groud 1
501 937 9916 127 Screw, ø1.4x1.5mm 2
502 937 9961 156 Screw, ø2x2mm 1
503 937 0105 953 Screw, ø1.4x2.5mm 1
504 937 0161 900 Screw, ø1.7x5mm 1
505 937 9961 130 Screw, ø1.4x3mm 3
506 937 9961 143 Screw, ø1.7x6mm 4
507 937 9961 169 Screw, ø1.4x4.5mm 2
509 937 9961 172 Screw, ø2x3mm 5
510 937 0163 500 Screw, ø1.7x3mm 2
511 937 0107 304 Screw, ø1.4x0.5mm 1
512 937 0161 609 Screw, ø1.7x3mm 3
513 937 9961 185 Screw, ø1.4x5mm 1
M901 937 0260 416 MD Spindle Motor Ass’y 1
M902 937 0260 306 MD Sled Motor Ass’y 1
M903 937 0260 209 MD Loading Motor Ass’y 1
SW1930 937 0254 901
Switch,Push Type [Write Pro]
1
SW1931 937 0255 007
Switch,Push Type [Disc Media]
1
SW1932 937 0254 804
Switch,Push Type [Loading]
1
SW1933 937 0254 804 Switch,Push Type [Record] 1
SW1934 937 0254 804 Switch,Push Type [Play] 1
SW1936 937 0152 207 Switch,Push Type [Lead in] 1
PWB-E 937 0269 213 MD Main P.W.B. Assembly 1
To Next Page
