Denon DBP-1611UD

10
2. BD MAIN UNIT

ASSY
s
(1) DisconnecttheconnectorwiresandFFCcables,thenremovethescrews.
(2) Removethescrews.
(3) Removethescrew.
Proceedin  TOP COVER
FRONT PANEL ASSY
→
BD MAIN UNIT ASSY
→
BACPANELASSY
BDMAINUNIT ASSY
CN
FFCcable
POWER PWBUNIT
FFCcable
P2
Shootingdirection:A
Viewfromthebottom
