Denon DBP-1611UD

61
PARTS LIST OF EXPLODED VIEW
dfgh
zParts indicated by "nsp" on this table cannot be supplied.
zP.W.B. ASS'Y indicated by "nsp" on this table cannot be supplied. When repairing the P.W.B. ASS'Y, check the board parts list and order replacement parts.
zParts indicated by the " ★ " mark are not illustrated in the exploded view.
zThe parts listed below are only for maintenance, might differ from the parts used in the unit in appearances or dimensions.
Note: The symbols in the column "Remarks" indicate the following destinations.
BK : Black model SP : Premium Silver model
E3 : U.S.A. & Canada model E2 : Europe model E2R : Russia model
EA : Australia model E1C : China model E1 : Asia model
Ref.No. Part No. Part Name Remarks Q'ty New
2 972631000030S POWER PWB UNIT(DBP1611) 7025HV1002014 1
3 972631000070S REMOTE PWB UNIT 7025HV1003011 1
4 nsp KEY PWB UNIT 7025HV1002212 1
5 963633100030S SUB POWER PWB UNIT ASSY 7025HV1002015 1
6 972631000050D DISPLAY PWB UNIT ASSY(DBP1611) 7025HV1002211 1
8 nsp CHASSIS 3200213776000S 1
9 nsp FOOT 4000210641000S 4
10 nsp RUBBER PAD 4050211335000S 4
A 972304000010S BD MAIN UNIT(DBP1611) 7025HV1002010 1
1 nsp MAIN PWB UNIT ASSY - 1
11 963309100070S BD MECHA UNIT ASSY(DBP1611) 8038041669010S 1
★
67 nsp 9P FFC(1.0) N711091033810S 1
12 nsp MECHA BRACKET 4010215106100S 1
13 nsp DAMPER (60X10) 4050213415000S 1
14 nsp DAMPER (40X35) 4050213425000S 1
15 nsp DAMPER (75X35) 4050213435000S 1
17 nsp HEAT SHEET (25X25 T1.5) 1210211539000S 1
19 nsp HEAT SINK 2120211958000S 1
20 nsp SPRING 3720210466000S 2
21 nsp FRANGE NUT-M3 1520210416000S 2
22 nsp MECHA COVER 4010215116000S 1
23 nsp DAMPER SHEET 50X40 CGX1A418Z 4050213445000S 2
24 nsp C1M LASER CAUTION 5507000004450S 1
48 nsp BUFFER 45x140x2t - 1
49 nsp BUFFER 30x140x2t - 1
50 nsp BUFFER 40x110x2t - 2
★
68 nsp FFC 45P 110MM 0.5MM AD L301101450010S 1
16 nsp LICENSE LABEL 5507000005460S 1
25 nsp REAR PANEL (1611E3) E3 3207213786000S 1
NOTE :
To replace the POWER PWB UNIT (DBP1611), attach the following parts before replacement, except the E3 model.
JP1 972641000510S AC INLET E2,E2R,EA,E1C,E1
NOTE :
To replace the REMOTE PWB UNIT, remove the following parts. Please set a resistor according to 46 page of
"Destination Setting".
[S401] [JK3]
NOTE :
After replace the BD MAIN UNIT, when the remote controller does not work, please use the following parts.
★
60 00MYU12090540 12P FFC reverse type
